hAP ac lite

RB952Ui-5ac2nD – hAP ac lite with 650MHz CPU, 64MB RAM, 5xLAN, built-in 2.4Ghz 802.11b/g/n two chain wirelesswith integrated antennas, built-in 5Ghz 802.11ac single chain wireless with integrated antenna, USB,plastic case, PSU, RouterOS L4, International version



Product Description

The hAP ac lite is a Dual-concurrent Access Point, that provides Wifi coverage for 2.4GHz and 5GHz frequencies at the same time.

Unit is equipped with a 650MHz CPU, 64MB RAM, five 10/100Mbps Ethernet ports (PoE output on port #5), dual-chain 802.11b/g/n 2.4GHz wireless, single chain 802.11ac 5GHz wireless, USB port for 3G/4G modem and a RouterOS L4 license.

We have two versions available – RB952Ui-5ac2nD (International) and RB952Ui-5ac2nD-US (USA). RB952Ui-5ac2nD-US (USA) is factory locked for 2412-2462MHz, 5170-5250MHz and 5725-5835MHz frequencies. This lock can not be removed. RB952Ui-5ac2nD (International) supports 2412-2484MHz and 5150MHz – 5875MHz range.

Product specifications

Product code RB952Ui-5ac2nD
CPU nominal frequency 650 MHz
CPU core count 1
Size of RAM 64 MB
10/100 Ethernet ports 5
Wireless chip model QCA9887
Wireless standards 802.11a/n/ac
Secondary wireless standards 802.11b/g/n
Secondary wireless chip model QCA9531
Number of USB ports 1
Power Jack 1
PoE in Yes
PoE out Yes
Supported input voltage 10 V – 30 V
Dimensions 113 x 89 x 28mm
Operating System RouterOS
Tested ambient temperature -30 + 70 C
License level 4
Antenna gain DBI 2
Max Power consumption 8W
USB slot type USB type A
Number of chains 1
Storage type FLASH
Storage size 16 MB
