The SXT LTE (product code RBSXTLTE3-7) is a special variant of our popular SXT device, and doesn’t include a 802.11 wireless device. Instead, it has a built in high quality LTE Category 3 modem for speeds of up to 100Mbit/s downlink and 50 Mbit/s uplink.
A perfect device for remote locations that are within cellular network coverage. Due to it’s professional LTE chip and high gain antenna, it can provide connectivity for your building even where cell phones can’t.
The signal LEDs show LTE signal level for easy positioning. The SXT LTE supports the popular LTE FDD bands 3 (1800MHz) and 7 (2600MHz), has a miniSIM slot and is not backwards compatible with older networks.
Product specifications
| Details | |
|---|---|
| Product code | RBSXTLTE3-7 |
| CPU nominal frequency | 400 MHz |
| CPU core count | 1 |
| Size of RAM | 64 MB |
| 10/100 Ethernet ports | 1 |
| Wireless chip model | GDM7240CB20BGT |
| PoE in | Yes |
| Supported input voltage | 11 V – 57 V |
| Voltage Monitor | Yes |
| PCB temperature monitor | Yes |
| Dimensions | 140x140x105mm |
| Operating System | RouterOS |
| Tested ambient temperature | -30 70 C |
| License level | 3 |
| Antenna gain DBI | 9 |
| CPU | AR7241 |
| Max Power consumption | 5W |
| Number of chains | 2 |
| Storage type | NAND |
| Storage size | 128 MB |
