Specification
- Dimensions 175.7 x 175.7 x 43.2 mm (6.92 x 6.92 x 1.70″)
- Weight 240 g (8.5 oz) With Mounting Kits 315 g (11.1 oz)
- Networking Interface (1) 10/100/1000 Ethernet Port
- Buttons Reset
- Antennas (1) Dual-Band Antenna, Tri-Polarity, 3 dBi
- Wi-Fi Standards 802.11 a/b/g/n/ac
- Power Method Passive Power over Ethernet (24V), (Pairs 4, 5 ; 7, 8 Return)
- Power Supply 24V, 0.5A Gigabit PoE Adapter*
- Maximum Power Consumption 6.5W
- Maximum TX Power 2.4 GHz 22 dBm 5 GHz 24 dBm
- BSSID Up to Four per Radio
- Power Save Supported
- Wireless Security WEP, WPA-PSK, WPA-Enterprise (WPA/WPA2, TKIP/AES)
- Certifications CE, FCC, IC
- Mounting Wall/Ceiling (Kits Included)
- Operating Temperature -10 to 70° C (14 to 158° F)
- Operating Humidity 5 to 95% Noncondensing
* Only the single-pack of the UAP-AC-LR includes a PoE adapter.
Advanced Traffic Management
- VLAN 802.1Q
- Advanced QoS Per-User Rate Limiting
- Guest Traffic Isolation Supported
- WMM Voice, Video, Best Effort, and Background
- Concurrent Clients 200
Supported Data Rates (Mbps)
- Standard Data Rates
- 802.11a 6, 9, 12, 18, 24, 36, 48, 54 Mbps
- 802.11n 6.5 Mbps to 450 Mbps (MCS0 – MCS23, HT 20/40)
- 802.11ac 6.5 Mbps to 867 Mbps (MCS0 – MCS9 NSS1/2, VHT 20/40/80)
- 802.11b 1, 2, 5.5, 11 Mbps
- 802.11g 6, 9, 12, 18, 24, 36, 48, 54 Mbps
