- Camera
- Lens2.8 mm, 3.6 mm, 6 mm fixed lens
- Horizontal Field Of View102.2° (2.8 mm), 79° (3.6 mm), 50.8° (6 mm)
- Lens MountM16
- Day & NightIR cut filter
- SynchronizationInternal synchronization
- Angle AdjustmentPan: 0° to 360°, Tilt:0° to 180°, Rotate: 0° to 360°
- Image Sensor8.29 megapixel progressive scan CMOS
- Signal SystemPAL/NTSC
- Frame RateTVI: [email protected], [email protected], [email protected], [email protected], [email protected], [email protected], [email protected] CVI: [email protected], [email protected] AHD: [email protected], [email protected] CVBS: 960H P/N
- Resolution3840 (H) × 2160 (V)
- Min. IlluminationColor: 0.01 Lux@(F1.2, AGC ON), 0 Lux with IR
- Shutter TimePAL: 1/12.5 s to 1/50,000 s NTSC: 1/15 s to 1/50,000 s
- Menu
- AGCYes
- Day/Night ModeAuto/Color/BW (Black and White)
- White BalanceAuto/Manual
- Backlight CompensationYes
- DWDR (Digital Wide Dynamic Range)105 dB
- LanguageEnglish
- FunctionsBrightness, Sharpness, DNR, Mirror, Smart IR, HLC
- Interface
- Video Output1 HD analog output
- Switch ButtonTVI/AHD/CVI/CVBS
- General
- Operating Condition-40 °C to 60 °C (-40 °F to 140 °F), humidity: 90% or less (non-condensation)
- Power Supply12 VDC ±25% *You are recommended to use one power adapter to supply the power for one camera.
- Power ConsumptionMax. 5.3 W
- MaterialMetal
- IR RangeUp to 30 m
- CommunicationUp the coax, Protocol: HIKVISION-C (TVI output)
- Dimensions58 mm × 61 mm × 159.8 mm (2.28″ × 2.40″ × 6.42″)
- WeightApprox. 345 g (0.76 lb.)
- Ingress ProtectionIP67
