- Door Station/Video Parameters
- CameraCMOS Low Illumination 2 MP HD Colorful 155° Fisheye Camera
- Resolution1920 × 1080
- Video Frame RateNTST: 30 fps PAL: 25 fps
- Video Compression StandardH.264
- Door Station/Audio Parameters
- Audio InputBuilt-in Omnidirectional Microphone
- Audio OutputBuilt-in Loudspeaker
- Audio QualityNoise Suppression and Echo Cancellation
- Audio Compression StandardG.711 U
- Audio Compression Rate64 Kbps
- Door Station/Light Supplement
- Light Supplement ModeIR Supplement
- Door Station/Device Interfaces
- IO Output1-ch 12 VDC Output
- RS-4851 RS-485 Half-Duplex Port
- Alarm InputDoor Magnetic Alarm, Tampering Alarm
- Network InterfaceTwo-Wire Interface
- I/O Input2
- Door Station/General
- MaterialStainless Steel
- Power Consumption≤12 W
- Working Temperature-30 °C to 60 °C (-22 °F to 140 °F)
- Working Humidity10% to 90%
- Dimension (L X W X H)169 mm x 110 mm x 44 mm (6.65″ x 4.33″ x 1.73″)
- Protection LevelIP 65
- Power InputPowered by DS-KAD709
- Door Station/System Parameters
- ProcessorHigh-Performance Embedded SOC Processor
- Operation SystemEmbedded Linux Operation System
- Door Station/Access Control Parameters
- Exit ButtonExit Button for Opening the Door
- Door Magnetic DetectionDetects Door Magnetic Status
- Door Station/Network Parameters
- Ethernet10/100 Mbps Self-Adaptive Ethernet
- Network ProtocolTCP/IP, RTSP
- Indoor Station/Display Parameters
- Display Screen7-inch Colorful TFT LCD
- Display Resolution1024 × 600
- Operation MethodCapacitive Touch Screen, Touch Button
- Operation InterfaceFlattened UI Operation Interface
- Indoor Station/Audio Parameters
- Audio InputBuilt-in Omnidirectional Microphone
- Audio OutputBuilt-in Loudspeaker
- Audio QualityNoise Suppression and Echo Cancellation
- Indoor Station/Device Interfaces
- Network InterfaceTwo-Wire Interface
- RS-4851, Half-duplex Interface
- Relay Output1
- Indoor Station/General
- Power SupplyPowered by DS-KAD709
- Power ConsumptionMax. 10 W
- Working Temperature-10 ° C to 55 ° C (14 ° F to 131 ° F)
- Working Humidity10% to 90%
- Dimension (L X W X H)196 mm × 133 mm × 25.75 mm (7.72″ × 5.24″ × 1.01″)
- InstallationWall Mounting
- Indoor Station/System Parameters
- ProcessorHigh-Performance Embedded SOC Processor
- Indoor Station/Video Parameter
- Video Compression StandardH.264
- Video Audio Distributor/Interfaces
- Interface Number1, 10/100M Interface
- Interface Type9-ch 2-wire Interface
- Video Audio Distributor/General
- Power Supply24 VDC
- Power Consumption60 W
- Working Temperature-10 ℃ to 55 ℃
- Working Humidity10% to 90%, No Condensing
- Dimension112.2 mm x 111 mm x 66 mm (4.42″ × 4.37″ × 2.60″)
