HAC-HFW1200DP - 2MP HDCVI IR Bullet Camera

* The parameters and datasheets below

can only be applied to 1200-S5 series

> Max 30fps@1080P

> CVI/CVBS/AHD/TVI switchable

> 3.6mm fixed lens (6mm, 8mm optional)

> Max. IR length 80m, Smart IR

> IP67, DC12V

Camera
Image Sensor 1/2.7 inch CMOS
Effective Pixels 1920(H)×1080(V), 2MP
Scanning System Progressive
Electronic Shutter Speed PAL: 1/25s–1/100000s
NTSC: 1/30s–1/100000s
S/N Ratio >65dB
Minimum Illumination 0.02Lux/F1.9, 30IRE, 0Lux IR on
Fill Light Working Distance 80 m (262.5 ft)
IR On/Off Control Auto; manual
IR LED Number 2
Pan/Tilt/Rotation Range Pan: 0°–360°
Tilt: 0°–87°
Rotation: 0°–360°
Lens
Lens Type Fixed-focal
Mount Type M12
Focal Length 3.6 mm; 6 mm; 8 mm
Max. Aperture F1.9
Field of View 3.6 mm: 100° x 84° x 45° (diagonal x horizontal x vertical)
6 mm: 60° x 56° x 30° (diagonal x horizontal x vertical)
8 mm: 46° x 40° x 22° (diagonal x horizontal x vertical)
Iris Type Fixed iris
Close Focus Distance 3.6 mm: 0.8 m (2.6 ft)

6 mm: 2 m (6.6 ft)

8 mm: 3.5 m (11.5 ft)

DORI Distance Lens Detect Observe Recognize Identify
3.6 mm 49.7 m (163.1 ft) 19.9 m (65.3 ft) 9.9 m

(32.5 ft)

5 m

(16.4 ft)

6 mm 82.8 m (271.7 ft) 33.1 m (108.6 ft) 16.6 m (54.5 ft) 8.3 m

(27.2 ft)

8 mm 110.3 m (361.9 ft) 44.1 m (144.7 ft) 22.1 m (72.5 ft) 11 m

(36.1 ft)

Video
Frame Rate CVI: 1080P@25/30fps; 720P@25/30fps; 720P@50/60fps;
AHD: 1080P@25/30fps; 720P@25/30fps;
TVI: 1080P@25/30fps; 720P@25/30fps; 720P@50/60fps;
CVBS: 960H
Resolution 1080P (1920×1080); 720P (1280×720); 960H (960× 576/960×480)
Day/Night Auto switch by ICR
BLC BLC/HLC/DWDR
WDR DWDR
White Balance Auto; manual
Gain Control Auto; manual
Noise Reduction 2D NR
Smart IR Yes
Electronic Defog Yes
Mirror Off/On
Privacy Masking Off/On (8 area, rectangle)
Certifications
Certifications CE (EN55032:2015, EN 61000-3-2:2014, EN 61000-3-3:2013, EN55024:2010+A1:2015, EN 55035:2017, EN50130-4:2011+A1:2014)
FCC (CFR 47 FCC Part 15 subpartB, ANSI C63.4-2014)
UL (UL60950-1+CAN/CSA C22.2 No.60950-1)
Port
Video Output Video output choices of CVI/TVI/AHD/CVBS by one BNC port
Power
Power Supply 12V ±30% DC
Power Consumption Max 4.9W (12V DC, IR on)
Environment
Operating Temperature -40°C to +60°C (-40°F to 140°F); <95% (non-condensation)
Storage Temperature -40°C to +60°C (-40°F to 140°F); <95% (non-condensation)
Protection Grade IP67
Structure
Casing Mental throughout the whole casing
Camera Dimensions 241.8 mm × 90.4 mm × 90.4 mm ( 9.52″ × 3.56″ × 3.56″ )
Net Weight 0.59 Kg (1.30 lb)
Gross Weight 0.69 Kg (1.52 lb)
