HAC-HFW1509TLM(-A)-LED - 5MP Full-color Starlight HDCVI Bullet Camera

> Full-color starlight

> 40 m LED distance

> Max. 20fps@5MP

> CVI/CVBS/AHD/TVI switchable

> Built-in mic (-A)

> 3.6 mm fixed lens

> IP67, 12V±30% DC

5

Camera
Image Sensor 1/2.7 inch CMOS
Effective Pixels 2592 (H) × 1944 (V), 5Mp
Scanning System Progressive
Electronic Shutter Speed PAL: 1/25s–1/100000s
NTSC: 1/30s–1/100000s
S/N Ratio >65dB
Minimum Illumination 0.005Lux/F1.2, 0Lux White Light on
Fill Light (White Light) Distance Distance up to 40 m (131.23 ft)
Fill Light On/Off Control Auto; manual
Fill Light Number 2
Pan/Tilt/Rotation Range Pan: 0°–360°
Tilt: 0°–180°
Rotation: 0°–360°
Lens
Lens Type Fixed-focal
Mount Type M12
Focal Length 3.6 mm
Max. Aperture F1.2
Field of View 3.6 mm: 111° × 83° × 56°

(diagonal × horizontal × vertical)

Iris Type Fixed iris
Close Focus Distance 3.6 mm: 2.1 m (6.89 ft)
DORI Distance Lens Detect Observe Recognize Identify
3.6 mm 80.0 m (262.5 ft) 32.0 m (105.0 ft) 16.0 m (52.5 ft) 8.0 m

(26.2 ft)

Video
Frame Rate CVI:
PAL: 5M@20fps, 4M@25fps, 1080P@25fps;
NTSC: 5M@20fps, 4M@30fps, 1080P@30fps
AHD: PAL: 5M@20fps, 4M@25fps;
NTSC: 5M@20fps, 4M@30fps
TVI: PAL: 5M@20fps, 4M@25fps;
NTSC: 5M@20fps, 4M@30fps
CVBS: PAL: 960H;
NTSC: 960H
Resolution 5M (2592 × 1944); 4M (2560 × 1440); 1080P (1920 × 1080); 960H (704 × 576/704 × 480);
BLC BLC/HLC/WDR
WDR DWDR
White Balance Auto; manual
Gain Control Auto; manual
Noise Reduction 2D NR
Smart Light Yes
Mirror Off/On
Privacy Masking Off/On (8 area, rectangle)
Certifications
Certifications CE (EN55032, EN55024, EN50130-4,EN60950-1)
FCC (CFR 47 FCC Part 15 subpartB, ANSI C63.4-2014)
UL (UL60950-1+CAN/CSA C22.2 No.60950-1)
Port
Video Output Video output choices of CVI/TVI/AHD/CVBS by one BNC port
Audio Interface
Audio Input Built-in mic (-A)
Power
Power Supply 12V ±30% DC
Power Consumption Max 5.0W (12V DC, white light on)
Environment
Operating Temperature -40°C to +60°C (-40°F to 140°F); <95% (non-condensation)
Storage Temperature -40°C to +60°C (-40°F to 140°F); <95% (non-condensation)
Protection Grade IP67
Structure
Casing Metal front cover + plastic main body + metal bracket
Camera Dimensions 198.4 mm × 80.2 mm × 76.2 mm (7.81″ × 3.16″ × 3.00″)
Net Weight 0.29 Kg (0.64 lb)
Gross Weight 0.44 Kg (0.97 lb)
