SensoMAG S30 is an optical-smoke detector with digital processing algorithm. The detector is designed to detect smoke in the very early stage of the fire situation.
SensoMAG S30 is suitable for installing in any conventional fire alarm system designed with fire alarm panel with fire alarm threshold between 10mA and 15mA.
SensoMAG S30 is a high sensitive optical smoke detector. It is suitable for applications where early detection of smoke or fire is with great importance, for example office buildings, supermarkets, schools, etc.
|Supply voltage U||9-30 VDC (Nom. 12/24 VDC)|
|Alarm state current||– base type B24 and B24D: 20mA/12-30V;
– base type B24RD: 33mA/12V, 49mA/ 24V, 57mA/30V
– base type B12: 18mA/9V, 29mA/12V, 32mA/15V
|Output in alarm state at terminal RI||20mA (max)/-3.3V|
|Degree of protection||IP 30|
|Operational temperature range||-10 / +60°С|
|Relative humidity resistance||(93 ± 3) % at 40°С|
|Dimensions (incl. base)||diameter 102 mm, h 42 mm|
|Weight (incl. base)||160 g|
