Huawei MA5683T GPON OLT

19’Chassis Fan 2x SCUN,2x PRTE ,2x GICF,1x GPBD with 8pcs C+modules,Power cords and ect

Category: Tags: ,

2,218.00

Quantity

Product Description

System performance
Backplane bus switching capacity 1.5 Tbit/s
System L2 packet forwarding rate Power SCUB: 72 Mpps
SCUN: 726 Mpps(Active/Standby mode), 1452 Mpps(Load-sharing mode)
SCUK: 726 Mpps(Active/Standby mode), 1452 Mpps(Load-sharing mode)
SCUF: 190 Mpps
SCUH: 1428 Mpps(Active/Standby mode), 2856 Mpps(Load-sharing mode)
Control board switching capacity SCUB: 48 Gbit/s
SCUN: 480 Gbit/s(Active/Standby mode), 960Gbit/s(Load-sharing mode)
SCUK: 480 Gbit/s(Active/Standby mode), 960Gbit/s(Load-sharing mode)
SCUF: 128 Gbit/s
SCUH: 960 Gbit/s(Active/Standby mode), 1920Gbit/s(Load-sharing mode)
Switching/Forwarding delay Short forwarding delay:The 100 Mbit/s Ethernet port sends the 64-byte Ethernet packets at a delay shorter than 20 μs.
BER in full load BER of port when transmitting data in full load < 10 e-7
System performance
System Redundant configuration
System availability in typical configuration >99.999%
Mean Time Between Failures (year) ≈45
Configuration
Maintenance port Number of 10 Mbit/s/100 Mbit/s maintenance Ethernet ports: 1
Number of serial ports for local/remote maintenance: 1
Monitoring port Number of environment monitoring serial ports: 1
Maximum number of GPON ports in a subrack 96
Maximum number of 10G GPON ports in a subrack 24
Maximum number of P2P FE ports in a subrack 288
Maximum number of P2P GE ports in a subrack 288
Maximum number of upstream ports (GE ports in the GIU slot) in a subrack 8
Maximum number of upstream ports (10GE ports in the GIU slot) in a subrack 4
Management ports
Outband management Ethernet port (RJ-45) SCUB/SCUN/SCUF/SCUH control board: 1 Port Board
Local serial port (Console) SCUB/SCUN/SCUF/SCUH control board: 1 Port Board
Upstream ports
GE electrical port GICE: 4 Ports Board
GICG: 2 Ports Board
GE optical port GICF/GICK: 2 Ports Board
SCUB/SCUN/SCUH/GICD/GSCA: 4 Ports Board
ETHB/SPUA/SPUF: 8 Ports Board
SPUC: 40 Ports Board
10GE optical port X2CS/SPUA: 2 Ports Board
SPUC: 4 Ports Board
SPUF: 8 Ports Board
E1 port TOPA: 16 Ports Board
STM-1 upstream optical port TOPA: 2 Ports Board
PON upstream optical port P2CA: 2 Ports Board  (One PON port is available and the other is backup.)
Service ports
GPON port GPBD/GPBH: 8 Ports Board
GPFD: 16 Ports Board
10G GPON port XGBC: 4 Ports Board
XGBD: 8 Ports Board
P2P GE optical port OPGD/OPGE: Single-fiber bi-directional: 48 Ports Board, Two-fiber bi-directional: 24 Ports Board
P2P FE optical port OPFA: 16 Ports Board
OPGD/OPGE: Single-fiber bi-directional: 48 Ports Board, Two-fiber bi-directional: 24 Ports Board
Ethernet optical port ETHB: 8 Ports Board
E1 port H802EDTB: 16 Ports Board
Device Specifications
Dimensions (W x D x H excluding mounting brackets) 442.00 mm x 283.20 mm x 263.90 mm
Dimensions (W x D x H, including mounting brackets) 535.00 mm x 283.20 mm x 263.90 mm, for ETSI cabinet
482.60 mm x 283.20 mm x 263.90 mm, for IEC cabinet
Weight (empty chassis) 7.0kg
Working environment temperature For an indoor cabinet
Configured with 1 subrack: -25°C to +65°C
Configured with 2 subracks: -25°C to +55°C
Working environment humidity 5% RH to 95% RH
Atmosphere pressure 61 kPa to 106 kPa
Altitude < 4000 m
