HAC-HDW1239TL-LED - 2M Full-color Starlight HDCVI Eyeball Camera

>Full-color starlight
>20m LED distance
>Max. 30fps@1080P
>CVI/CVBS/AHD/TVI switchable
>Built-in mic(-A)
>3.6mm fixed lens(2.8mm Optional)
>IP67, 12V±30% DC

  • Camera
    Image Sensor 1/2.8 inch 2.16 Mega Pixels CMOS
    Effective Pixels 1920 (H)×1080 (V), 2MP
    Electronic Shutter Speed PAL:1/25s–1/100000s
    NTSC:1/30s–1/100000s
    Minimum Illumination 0.005Lux/F1.6, 30IRE, 0Lux white Light on
    Fill Light (White Light) Distance Distance up to 20m (65.61ft)
    Fill Light On/Off Control Auto; Manual
    Fill Light Number 1
    Pan/Tilt/Rotation Range Pan: 0°–360°
    Tilt: 0°–78°
    Rotation: 0°–360°
    Lens
    Lens Type Fixed-focal
    Mount Type M12
    Focal Length 2.8m/3.6mm
    Max. Aperture F1.6
    Angle of View 2.8mm: 126.2°×106.0°×56.5° (diagonalxhorizontalxvertical)
    3.6mm: 103.6°x86.9°x46.3°(diagonalxhorizontalxvertical)
    Iris Type Fixed iris
    Close Focus Distance 2.8mm: 0.6m (1.97ft)
    3.6mm: 1.2m (3.94ft)
    DORI Distance Lens Detect Observe Recognize Identify
    2.8mm 38.6m (126.6ft) 15.4m (50.5ft) 7.7m (25.3ft) 3.9m (12.8ft)
    3.6mm 55.2m (181.1ft) 22.1m (72.5ft) 11.0m (36.0ft) 5.5m (18.0ft)
    Video
    Video Frame Rate CVI:
    PAL: 1080@25fps, 720@25fps, 720@50fps;
    NTSC: 1080@30fps, 720@30fps, 720@60fps
    AHD: PAL: 1080@25fps,720@25fps;
    NTSC: 1080@30fps,720@30fps
    TVI: PAL: 1080@25fps,720@25fps,720@50fps;
    NTSC: 1080@30fps,720@30fps,720@60fps
    CVBS: PAL: 960×576H;
    NTSC: 960×480H
    BLC BLC/HLC/WDR
    WDR DWDR
    White Balance Auto; Manual
    Gain Control Auto; Manual
    Noise Reduction 2D NR
    Smart Light Yes
    Electronic Defog Yes
    Digital Zoom 16X
    Mirror Off/On
    Privacy Masking Off/On (4 area, rectangle)
    Certification
    Certifications CE (EN55032, EN55024, EN50130-4,EN60950-1)
    FCC (CFR 47 FCC Part 15 subpartB, ANSI C63.4-2014)
    UL (UL60950-1+CAN/CSA C22.2 No.60950-1)
    Interface
    Audio Interface Built-in mic(-A)
    Port
    Video Port Video output choices of CVI/TVI/AHD/CVBS by one BNC port
    Power
    Power Supply 12V ±30% DC
    Power Consumption Max 3W (12V DC, white light on)
    Environment
    Operating Temperature -40°C to +60°C (-40°F to 140°F);

    <95% (non-condensation)

    Storage Temperature -40°C to +60°C (-40°F to 140°F);

    <95% (non-condensation)

    Protection Grade IP67
    Structure
    Casing Inner core: metal+plastic; cover: plastic;

    pedestal: plastic

    Dimensions φ97mm×85.8mm (φ3.82″×3.38″)
    Net Weight 0.22Kg (0.49lb)
    Gross Weight 0.28Kg (0.62lb)

HAC-HDW1239TL-LED - 2M Full-color Starlight HDCVI Eyeball Camera
