48V 24W Passive PoE Injector

POE48-24W
● 48V 24 Watts Passive PoE power supply
● 1 10/100M Ethernet Input port
● 1 10/100M PoE Output port
● Plug&play, simple setup with no configuration needed

Disponueshmëria : S’ka stok
Kodi i produktit :7631

Model POE48-24W
No. of channels 1
Pass Through Data Ratesi 10/100Mbps
Power over Ethernet Output Pin Assignment and Polarity: 1/2 (-), 3/6 (+)
Output Power Voltage: 54VDC
User Port Power: 24W max
Input Power Requirements AC Input Voltage: 100 to 240 VAC
AC Input Current: 0.5A 100-240 VAC
AC Frequency: 50 to 60 Hz
Dimensions 83.5mm x 42.8mm x 30.8mm
Indicators System Indicator: AC Power
User Indicator: Channel Power
Connectors Shielded RJ-45, EIA 568A and 568B
Protection Over current protection
Over load protection
Over voltage protection
Anti-interference protection
Environmental Conditions Operating Ambient Temperature:-40 to 40℃
Operating Humidity: Maximum 85%, Non-condensing
Storage Temperature:-40 to 50℃
Storage Humidity: Maximum 90%, Non-condensing
