60W Gigabit PoE+/PoE Injector

POE300
● Up to 60 watts PoE power supply
● 1 10/100/1000M Ethernet Input port
● 1 10/100/1000M PoE Output port
● IEEE 802.3bt/at/af standard compliant
● Plug&play, simple setup with no configuration needed

39.20 €



Model POE300
No. of channels 1
Pass Through Data Ratesi 10/100/1000Mbps
Power over Ethernet Output Pin Assignment and Polarity: 1/2 (-), 3/6 ( ),4/5 ( ), 7/8 (-),

Output Power Voltage: 53Vdc

User Port Power: 60W
Input Power Requirements AC Input Voltage: 100 to 240 VAC
AC Input Current: 0.5A 100-240 VAC
AC Frequency: 50 to 60 Hz
Dimensions 145mm x 60mm x 40mm
Indicators System Indicator: AC Power
User Indicator: Channel Power
Connectors Shielded RJ-45, EIA 568A and 568B
Regulatory Compliance IEEE 802.3af (15.4W)
IEEE 802.3at (30W)
IEEE 802.3bt (60W)
Environmental Conditions Operating Ambient Temperature:0 to 40℃
Operating Humidity:Maximum 85%, Non-condensing
Storage Temperature:-40 to 60℃
Storage Humidity:Maximum 85%, Non-condensing
Kodi i produktit : 7629 Kategori:
