HAC-HDW1400TMQ - 4MP HDCVI Quick-to-install IR Eyeball Camera

* The parameters and datasheets below can only be applied to 1400-S3 series

> Max 30fps@4MP

> Quick-to-install eyeball saves installation time

> CVI/CVBS/AHD/TVI switchable

> 3.6mm fixed lens (2.8mm, 6mm optional)

> Built-in mic(-A)

> Max. IR length 60m, Smart IR

> IP67, DC12V

Camera
Image Sensor 1/2.7 inch CMOS
Max. Resolution 2560(H)×1440(V)
Pixel 4MP
Scanning System Progressive
Electronic Shutter Speed PAL: 1/25s–1/100000s
NTSC: 1/30s–1/100000s
S/N Ratio >65dB
Min. Illumination 0.02Lux/F2.0, 30IRE, 0Lux IR on
Illumination Distance 60 m (196.9 ft)
Illuminator On/Off Control Auto; manual
Illuminator Number 2
Pan/Tilt/Rotation Range Pan: 0°–360°
Tilt: 0°–78°
Rotation: 0°–360°
Lens
Lens Type Fixed-focal
Mount Type M12
Focal Length 2.8 mm; 3.6 mm; 6 mm
Max. Aperture F2.0
Field of View 2.8 mm: 125° x 105° x 56°

(diagonal x horizontal x vertical)
3.6 mm: 104° x 87° x 47°

(diagonal x horizontal x vertical)
6 mm: 62° x 54° x 31°

(diagonal x horizontal x vertical)

Iris Type Fixed iris
Close Focus Distance 2.8 mm: 0.7m (2.3 ft)

3.6 mm: 1.1m (3.6 ft)

6 mm: 2.7m (8.9 ft)

DORI Distance Lens Detect Observe Recognize Identify
2.8 mm 49.8m (163.4 ft) 19.9m

(65.3 ft)

10m

(32.8 ft)

5m

(16.4 ft)

3.6 mm 64m

(210.0 ft)

25.6m

(84 ft)

12.8m

(42 ft)

6.4m

(21 ft)

6 mm 106.7m (350.1 ft) 42.7m (140.1 ft) 21.3m

(69.9 ft)

10.7m

(35.1 ft)

Video
Frame Rate CVI:

PAL: 4M@25fps; 1080P@25fps;

NTSC: 4M@30fps; 1080P@30fps

AHD:

PAL: 4M@25fps;

NTSC: 4M@30fps

TVI:

PAL: 4M@25fps;

NTSC: 4M@30fps

CVBS:

PAL: 960H;

NTSC: 960H

Resolution 4M (2560 × 1440); 1080P (1920 × 1080); 960 H (960 × 576/960 × 480)
Day/Night Auto switch by ICR
BLC BLC/HLC/DWDR
WDR DWDR
White Balance Auto; manual
Gain Control Auto; manual
Noise Reduction 2D NR
Smart IR Yes
Electronic Defog Yes
Mirror Off/On
Privacy Masking Off/On (8 area, rectangle)
Certifications
Certifications CE (EN55032:2015, EN 61000-3-2:2014, EN 61000-3-3:2013, EN55024:2010+A1:2015, EN 55035:2017, EN50130-4:2011+A1:2014)
FCC (CFR 47 FCC Part 15 subpartB, ANSI C63.4-2014)
UL (UL60950-1+CAN/CSA C22.2 No.60950-1)
Port
Audio Output One channel built-in mic (-A)
Video Output Video output choices of CVI/TVI/AHD/CVBS by one BNC port
Power
Power Supply 12V ±30% DC
Power Consumption Max 5.2W (12V DC, IR on)
Environment
Operating Temperature -40°C to +60°C (-40°F to 140°F); <95% (non-condensation)
Storage Temperature -40°C to +60°C (-40°F to 140°F); <95% (non-condensation)
Protection Grade IP67
Structure
Casing Metal dome+metal cover+plastic decorative ring
Camera Dimensions φ121.9 mm × 99.1 mm (φ4.8″ × 3.9″)
Net Weight 0.4 Kg (0.88 lb)
Gross Weight 0.6 Kg (1.32 lb)
