- Camera
- Image Sensor5 MP CMOS
- Signal SystemPAL/NTSC
- Frame RateTVI: [email protected], [email protected], [email protected], [email protected], [email protected] CVI: [email protected], [email protected] AHD: [email protected], [email protected], [email protected] CVBS: PAL/NTSC
- Resolution2560 (H) × 1944 (V)
- Min. Illumination0.01 [email protected](F1.2, AGC ON), 0 Lux with IR
- Shutter TimePAL: 1/25 s to 1/50, 000 s NTSC: 1/30 s to 1/50, 000 s
- Lens2.8 mm, 3.6 mm, 6 mm fixed lens
- Horizontal Field Of View2.8 mm, horizontal FOV: 85.5°,vertical FOV: 63.7°, diagonal FOV: 110.7° 3.6 mm, horizontal FOV: 80.1°, vertical FOV: 63.7°, diagonal FOV: 105.9° 6 mm, horizontal FOV: 57.1°, vertical FOV: 43.1°, diagonal FOV: 72.5°
- Lens MountM12
- Day & NightICR
- WDR (Wide Dynamic Range)Digital WDR
- Angle AdjustmentPan: 0 to 360°, Tilt: 0 to 75°,Rotation 0 to 360°
- Menu
- Image ModeSTD/HIGH-SAT
- AGCSupport
- Day/Night ModeAuto/Color/BW (Black and White)
- White BalanceATW/MANUAL
- LanguageEnglish
- FunctionsBrightness, Sharpness, Mirror, Smart IR
- Interface
- Video OutputSwitchable TVI/AHD/CVI/CVBS
- General
- Operating Condition-40° C to 60° C (-40° F to 140° F), Humidity 90% or less (no condensation)
- Power Supply12 VDC ± 25% *You are recommended to use one power adapter to supply the power for one camera.
- Power ConsumptionMax. 3.7 W
- Protection LevelIP67
- MaterialMetal
- IR RangeUp to 30 m
- CommunicationHIKVISION-C
- Dimensions82.6 mm × 90 mm × 79.37 mm (3.25″ × 3.54″ × 3.12″)
- WeightApprox. 289.5 g (0.64 lb.)
