HAC-HFW1801TL-A – 4K HDCVI IR Bullet Camera

Availability:

Out of stock


> 120dB True WDR, 3DNR

> Max. 4K resolution

> CVI/CVBS/AHD/TVI switchable

> Built-in mic (-A)

> Fixed lens (2.8mm;3.6mm;6mm optional)

> Max. IR length 80m, Smart IR

> IP67, 12V±30Ü

Camera
Image Sensor 1/2.7 inch CMOS
Effective Pixels 3840 (H)×2160 (V), 4K
Electronic Shutter Speed PAL: 1/3s-1/100000s
NTSC: 1/4s-1/100000s
Minimum Illumination 0.03Lux/F2.0, 30IRE, 0Lux IR on
IR Distance Distance up to 80m (262.47ft)
IR On/Off Control Auto/Manual
IR LEDs 2
Pan/Tilt/Rotation Range Pan: 0°–360°

Tilt: 0°–180°

Rotation: 0°–360°

Lens
Lens Type Fixed-focal
Mount Type M12
Focal Length 2.8mm; 3.6mm; 6mm
Max. Aperture F2.0
Angle of View 2.8mm: 125°×105°×56° (diagonal×horizontal×vertical)

3.6mm: 104°×87°×47° (diagonal×horizontal×vertical)

6mm: 62.4°×54.7°×31.3° (diagonal×horizontal×vertical)

Iris type Fixed Iris
Close Focus Distance 1m/1.8m/3.6m (3.28ft/5.91ft/11.81ft)
DORI Distance Lens Detect Observe Recognize Identify
2.8mm 75m(26ft) 30m(98ft) 15m(49ft) 8m(26ft)
3.6mm 107m(351ft) 43m(141ft) 21m(69ft) 11m(36ft)
6mm 160m(525ft) 64m(210ft) 32m(105ft) 16m(52ft)
Video
Video Frame Rate CVI: 4K@15fps; 5M@20fps; 4M@25fps/30fps
CVBS: PAL/NTSC
AHD: 4K@15fps; 5M@20fps; 4M@25fps/30fps
TVI: 4K@15fps; 5M@20fps; 4M@25fps/30fps
Resolution 4K (3840×2160); 5M (2592×1944); 4M (2560×1440); 960H (960× 576/960×480)
Day/Night Auto switch by ICR
BLC BLC/HLC/WDR
WDR 120dB/WDR
White Balance Auto; manual
Gain Control Auto; manual
Noise Reduction 2D&3D NR
Smart IR Yes
Electronic Defog Yes
Digital Zoom 4X
Mirror Off/On
Privacy Masking Off/On (8 Area, Rectangle)
Certifications
Certifications CE (EN55032, EN55024, EN50130-4)
FCC (CFR 47 FCC Part 15 subpartB, ANSI C63.4-2014)
UL (UL60950-1 CAN/CSA C22.2 No.60950-1)”
Interface
Audio Interface Built-in Mic (-A)
Port
Video Port Video output choices of CVI/TVI/AHD/CVBS by one BNC port
Power
Power Supply 12V±30% DC
Power Consumption Max 6.6W (12V DC, IR on)
Environment
Operating Temperature -40°C to 60°C (-40°F to 140°F); <95%

(non-condensation)

Storage Temperature -40°C to 60°C (-40°F to 140°F); <95%

(non-condensation)

Protection Grade IP67
Structure
Casing Metal front cover plastic main body plastic bracket
Dimensions 240.7mm×90.7m×90.4mm (9.48”×3.57”×3.56”)
Net Weight 280g (0.62lb)
Gross Weight 420g (0.93lb)
