HDMI Splitter 1x2

20.00

4K HDMI Splitter 1X2 distributes 1 HDMI source to 2 HDMI displays simultaneously with 3D compatibility. It provides HD solutions for TV retail and display sites, TVs, STBs and DVDs. Ideal for projector factories, noise, space and security issues, data center control, information distribution, boardroom demonstrations, school and corporate training environments.

Features & Specifications

Features
1. One HDMI 1.4V signal input is split into two HDMI 1.4V sink devices
2. Support 3D and CEC
3. Digital audio formats such as DTS-HD / Dolby-realHD / LPCM7.1 / DTS / Dolby-AC3 / DSD / HD
Support for dark 30bit, 36bit, Blu-ray 24/50 / 60fs / XvYCc
5. Support signal retiming

Specifications
Input video signal: 0.501.0 volts p-p
Input DDC signal: 5 volt p-p (TTL)
Maximum single link range: 4K X 2K 30HZ
Output video: HDMI 1.4a + HDCP1.0 / 1.1 / 1.2 / 1.3
Resolution DTV / HDTV: 576i / 576P / 720p / 1080i / 1080p / 4K
HDMI version: HDMI 1.4a
Power: DC 5V
Digital audio formats: DTS-HD / true-HD / LPCM 7.1 / DTS / AC3 / DSD

Connection
1. Connect the input source and output monitor to the HDMI distributor.
See Connecting images.
2. Connect the DC 5V power to the splitter.
Please note that higher voltage power supplies may damage the splitter.
3. When the input source and output display are connected and turned on, the corresponding LED will light.
4. USB charging power supply, 5V USB power supply must be connected before using this HDMI distributor
