24-Port Gigabit Metal Switch ( GS1024 )


GS1024
● Complies with IEEE 802.3, IEEE 802.3u, IEEE802.3x and IEEE 802.3ab standards
● 24 10/100/1000Mbps Auto-Negotiation, Auto-MDI/MDIX ports provide smart switching between 10Mbps, 100Mbps and 1000Mbps hardware
● Non-blocking switching architecture enables full wire-speed packets forwarding and filtering
● Store-and-Forward switching method
● Supports 16K MAC address auto-learning and auto-agin

DATASHEET

50.64  63.05

Product Name 24-Port Gigabit Ethernet Switch
Product Model GS1024
Chipset RTL8382L 2*RTL8218B 2*RTL8231
Standards IEEE 802.3、IEEE 802.3u、IEEE802.3ab、IEEE802.3x、IEEE802.3az
Number of Ports 24 x 10/100/1000Mbps Auto-Negotiation ports
Network Media (Cable) 10Base-T: UTP category 3,4,5 cable (maximum 100m)
100Base-Tx: UTP category 5,5e cable (maximum 100m)
1000Base-T:UTP category 5e,6 cable (maximum 100m)
Transfer Method Store-and-Forward
MAC Address Table 8K
Switching Capacity 48Gbps
Packet Forwarding Rate 35.7Mbps
Packet Buffer 4.1 Mbit
Jumbo Frame 9K Bytes
LED indicators Per-Port 10M/100M Link/ACT:Orange
1000M Link/ACT:Green
Per Device Power :Green
Power Supply AC 100-240V/50-60Hz 12//1.5A internal power
Power Consumption Maximum: 15W(220V/50Hz)
Dimensions ( W x D x H ) 440*140*44mm
Environment Operating Temperature: 0℃ ~ 40℃
Storage Temperature: -40℃ ~70℃
Operating Humidity: 10%~90% non-condensing
Storage humidity: 5%~90% non-condensing
SKU: 7608 Categories: ,
