30W Gigabit PoE+/PoE Injector (POE200)

POE200
● Up to 30W Power Supply
● Supports 10/100/1000 Base-T applications
● LED indicators power input and PoE output
● Internal AC/DC converter no need for external power brick
● Easy plug-and-play installation
● Muti-protection

DATASHEET

16.10 €

Model POE200
No. of channels 1
Pass Through Data Ratesi 10/100/1000Mbps
Power over Ethernet Output Pin Assignment and Polarity: 1/2 (-), 3/6 ( )
Output Power Voltage: 54VDC
User Port Power: 30W max
Input Power Requirements AC Input Voltage: 100 to 240 VAC
AC Input Current: 0.5A 100-240 VAC
AC Frequency: 50 to 60 Hz
Dimensions 121mm x 50mm x 36mm
Indicators System Indicator: AC Power
User Indicator: Channel Power
Connectors Shielded RJ-45, EIA 568A and 568B
Protection Over current protection
Over load protection
Over voltage protection
Anti-interference protection
Environmental Conditions Operating Ambient Temperature:-40 to 40℃
Operating Humidity: Maximum 85%, Non-condensing
Storage Temperature:-40 to 50℃
Storage Humidity: Maximum 90%, Non-condensing
Kodi i produktit : 7627 Kategori:
