air Max 15dBi 2.4GHz Sector Antenna (AM-2G15-120)
145.00 €
Koha e arritjes së produktit : 13/06/2025 - 14/06/2025
Features:
Patent-pending next-generation technology achieves gain, cross-pol isolation, and beamshaping characteristics rivaling the highest quality cellular carrier basestation antennas in the world. Instantly pair with Rocket M5 to create a powerful AirMax 2×2 MIMO PtMP BaseStation. Rocket mount and weatherproof RF jumpers included.
Rocket M and AirMax BaseStation/Rocket Antennas have been designed to seamlessly work together. Installing Rocket M on AirMax BaseStation/Rocket Antennas requires no special tools, you simply snap it into place with the mount provided with the Antennas.
Specification:
| Mode | AM-2G15-120 |
| Dimensions* | 700 x 145 x 93 mm (27.56 x 5.71 x 3.66″) |
| Weight* | 4.0 kg (8.82 lbs) |
| Frequency Range | 2.3 – 2.7 GHz |
| Gain | 15.0 – 16.0 dBi |
| HPOL Beamwidth | 123° (6 dB) |
| VPOL Beamwidth | 118° (6 dB) |
| Electrical Beamwidth | 9° |
| Electrical Downtilt | 4° |
| Max. VSWR | 1.5:1 |
| Wind Survivability | 200 km/h (125 mph) |
| Wind Loading | 169 N @ 200 km/h (38 lbf @ 125 mph) |
| Polarization | Dual-Linear |
| Cross-pol Isolation | 28 dB Min. |
| ETSI Specification | EN 302 326 DN2 |
| Mounting | Universal Pole Mount, RocketM Bracket, and Weatherproof RF Jumpers Included |
