8-Port Gigabit Desktop Switch


TL-SG1008D

18.99  27.95

  • 8 Gigabit Auto-Negotiation RJ45 ports, Supports Auto MDI / MDIX
  • Green Ethernet technology saves the power up to 80%
  • IEEE 802.3x flow control provides reliable data transfer
  • Plastic case, desktop or wall-mounting design
  • Plug and play, no configuration required
SKU: 3032 Categories: , Tag:
HARDWARE FEATURES
Standards and Protocols IEEE 802.3i
802.3u
802.3ab
802.3x
Interface 8 10/100/1000Mbps RJ45 Ports
AUTO Negotiation/AUTO MDI/MDIX
Fan Quantity Fanless
Physical Security Lock No
External Power Supply External Power Adapter
(Output: 9VDC / 0.6A)
Jumbo Frame 15 KB
Switching Capacity 16 Gbps
Dimensions ( W x D x H ) 7.1 × 3.5 × 1.0 in.
(180 × 90 × 26 mm)
Max Power Consumption 4.6W
Max Heat Dissipation 15.8 BTU/h
SOFTWARE FEATURES
Transfer Method Store and Forward
MAC Address Table 4K
Advanced Functions Green Technology, saving power up to 80%
802.3x Flow Control, Back Pressure
OTHERS
Certification FCC, RoHs
Package Contents 8-Port Gigabit Desktop Switch TL-SG1008D
Power Adapter
Installation Guide
Environment Operating Temperature: 0℃~40℃ (32℉~104℉)
Storage Temperature: -40℃~60℃ (-40℉~140℉)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing
