AC1200 xPON Wi-Fi Router ( GP1200 )

A xPON Wi-Fi router for reliable FTTx solution deployment, featuring GPON/EPON dual modes, CWMP, OMCI, 4-queue QoS, and EasyMesh.

  •  1.15 GHz Dual-Core CPU
  •  Max 2.48 Gbps GPON / 1.25 Gbps EPON
  •  4-Stream Dual-Band Wi-Fi 5
  •  867 Mbps + 300 Mbps Wi-Fi 1
  •  1× SC/APC Slot
  •  4× Gigabit Ethernet Ports
  •  OMCI/OAM/TR069/TR098/TR181
  •  EasyMesh
Kodi i produktit : 9678 Kategori: ,
Model Version GP1200 1.0
CPU Chipset RTL9607C
CPU Details 1.15 GHz Dual-Core
Memory/Storage Flash/ROM 128 MB (1 Gbit) NAND
DDR/RAM 256 MB (2 Gbit) DDR3
xPON Protocols GPON (ITU G. 984 standard, Class B+)
EPON (802.3ah)
Speed
  • GPON: 2.488 Gbps Downstream / 1.244 Gbps Upstream
  • EPON: 1.25 Gbps Downstream / Upstream
Wavelength TX: 1310 nm
RX: 1490 nm
Max Transmission Distance 20 km
Wireless 5 GHz Wi-Fi Speed 867 Mbps
2.4 GHz Wi-Fi Speed 300 Mbps
5 GHz Wi-Fi Streams 2T2R (2×2 MIMO)
2.4 GHz Wi-Fi Streams 2T2R (2×2 MIMO)
Wi-Fi Antennas 2× Fixed
5 GHz Antenna Gain Max 5dBi
2.4 GHz Antenna Gain Max 5dBi
Beamforming True
Range Performance Max: 170 m (558 ft)
Indoor WiFi range varies depending on the layout and wall materials. See Wall Performance spec for placement suggestions.
Wall Performance One wooden walls with thickness < 10 cm (4”)
One concrete wall with thickness < 20 cm (7”)
Interfaces SC/APC Port 1
Gigabit RJ45 Ports 4
USB-A 2.0 Ports Optional for ISP Order
LED
  • Power
  • PON
  • LOS
  • Internet
  • 2.4 GHz Wi-Fi
  • 5 GHz Wi-Fi
  • WPS
  • LAN
Physical Buttons
  • Power On/Off Button
  • Reset Button
  • WPS Button
  • Wi-Fi On/Off Button
Power Input DC Jack
Power Power Methods DC
DC 12V 1A
Power Adapter Input: 100 ~ 240 V, 50/60 Hz AC
Output: 12V 1A DC
Reliability Environment Operating Temperature: 0 ℃ ~ 40 ℃ (32 ℉ ~104 ℉)
Storage Temperature: -40 ℃ ~ 70 ℃ (-40 ℉ ~ 158 ℉)
Humidity: 10% ~ 90% non-condensing
Storage Humidity: 5% ~ 95% non-condensing
Certifications FCC, CE
Mechanical Installation
  • Desktop
  • Wall-mount
Dimension 173×123.8×33 mm
6.81×4.87×1.3 inches
Product Weight 288 g (10.16 oz.)
Package Content
  • GP1200
  • Power Adapter
  • Ethernet Cable
  • Installation Guide
