airFiber Antenna 5GHz 30dBi 45deg
, ,

airFiber Antenna 5GHz 30dBi 45deg

Availability:

Out of stock

The AF-5G30-S45

  • 5.1 – 5.9 GHz Frequency Range
  • 30 dBi Gain
  • 30 dB F/B Ratio
  • 1.6:1 Max. VSWR
  • Up to 125 mph Wind Survivability



Operating within the 5.1 to 5.9 GHz frequency, the 2-pack of AF-5G30-S45 30 dBi Antennas for airFiber AF-5X 5 GHz Carrier Backhaul Radios from Ubiquiti Networks produce a reliable point-to-point signal complete with a 30 dBi gain. In addition to the strength of the signal, users also benefit from a 5.8° (3dB) beamwidth and a wind survivability rating of up to 125 mph. Installation has also been simplified thanks to the included pole mounting kit while the weatherproof design allows the antennas to be deployed nearly anywhere.

SKU: 10264 Categories: , , Tag:
Frequency
5.1-5.9 GHz
Gain
30 dBi
Beamwidth
+45°: 5.8° (3 dB)
-45°: 5.8° (3 dB)
F/B Ratio
30 dB
Maximum VSWR
1.6:1
Wind Loading
790 N @ 200 km/h (178 lbf @ 125 mph)
Wind Survivability
200 km/h (125 mph)
Polarization
Dual-linear
Cross-Pol Isolation
35 dB minimum
ETSI Specification
EN 302 326 DN2
Mounting
Universal pole mount, airFiber X Radio bracket, and weatherproof RF connectors included
Dimensions
25.6 x 25.6 x 15.2″ (650 x 650 x 386 mm)
Weight
16.31 lb (7.4 kg)
Packaging Info
Package Weight
43.8 lb
Box Dimensions (LxWxH)
28 x 28 x 11″
