airGrid M5 23 dBi

Utilizing InnerFeed technology, the new airGrid® M HP Series from Ubiquiti Networks represents the latest evolution of outdoor wireless broadband devices. The revolutionary InnerFeed technology integrates the entire radio system into the feedhorn of the antenna. airGrid M combines Ubiquiti’s InnerFeed and airMAX® (TDMA protocol) technologies to create a simple, yet extremely powerful and robust wireless CPE (Customer Premises Equipment). Complete antenna and radio system integration provides affordable cost/performance solutions to the wireless broadband industry. airGrid M operates in the worldwide, license‑free frequency range of either 2 GHz or 5 GHz, and features breakthrough performance of up to 100 Mbps in real outdoor throughput and incredible range of up to 30 km. The low-cost, high‑performance,
robust “all-in-one” design and light weight of airGrid M make it versatile and ideal in several different applications.

Integrated airMAX Technology

Unlike standard Wi-Fi protocol, the exclusive Ubiquiti Networks® airMAX Time Division Multiple Access (TDMA) protocol allows each client to send and receive data using pre-designated
time slots managed by an intelligent AP controller. This “time slot” method eliminates hidden node collisions and maximizes airtime efficiency. Compared to other systems in its class, the airGrid M delivers superior performance in reduced latency, throughput, and scalability.

• Intelligent QoS Priority is given to voice/video for seamless access.
• Scalability High capacity and scalability.
• Long Distance Capable of high‑speed, 30 km links.

Easy, No-Tool Assembly
With its updated mechanical design, assembling and disassembling the airGrid M is literally a snap. No tools are required. You simply snap the feed, antenna, mounting bracket and rear housing together for a secure, solid assembly.

Specification:

System Information

Processor: Specs Atheros MIPS 74Kc, 560 MHz
Memory Information: 64 MB DDR2, 8 MB Flash
Networking Interface: (1) 10/100 Ethernet Port

Regulatory / Compliance Information

Wireless Approvals: FCC Part 15.247, IC RS210, CE
RoHS Compliance: Yes

Physical / Electrical / Environmental

Enclosure Characteristics: Outdoor UV Stabilized Plastic
Mounting Kit: Pole Mounting Kit (Included)
Max. Power Consumption: 3W
Power Supply: 24V, 0.5A PoE Adapter (Included)
Power Method: Passive Power over Ethernet (Pairs 4, 5 ; 7, 8 Return)
Operating Temperature: -30 to 75° C (-22 to 167° F)
Operating Humidity: 5 to 95% Condensing
Shock and Vibration: ETSI300-019-1.4
ETSI Specification: EN 302 326 DN2

Dimensions (Mount Included): 370 x 270 x 260 mm (14.57 x 10.63 x 10.24″)
Weight (Mount Included): 1452 g (3.201 lb)
Wind Survivability: 200 km/h (125 mph)
Wind Loading: 58 N @ 200 km/h (13 lbf @ 125 mph)
Operating Frequency:
Worldwide: 5170 – 5875 MHz
USA: 5725 – 5850 MHz
Max. VSWR: 1.5:1
Gain: 23 dBi
