- General
- Power Supply12V DC
- Working Temperature-20°C to 65°C (-4°F to 149°F)
- Working Humidity10% to 90% (Non Condensing)
- Radio Frequency StandardISO 14443-A/ISO 11784/11785
- Reading Frequency13.56MHz/125KHz
- Reading Range≤50mm (≤1.97″)
- Audio AlertBeeper
- KeypadNo Keypad (DS-K1802E and DS-K1802M)Keypad with 12 Keys (0~9, *, #) (DS-K1802EK and DS-K1802MK)
- LED IndicatorPower Indicator, Status Indicator
- Protection LevelIP65
- Dimensions115.9mm×43.3mm×17mm (4.56″×1.70″×0.67″)
- Installing MethodWall Mounting with Screws; Do Not Support Gang Box
- System Parameters
- Processor8-bit
