EdgeSwitch 24-Port Lite Gigabit Switch

247.41

EdgeSwitch, 24-port, Lite, Non-POE

The Ubiquiti Networks ES-24-LITE is part of the EdgeSwitch family of products. It’s a dully managed Gigabit switch designed to deliver robust performance and intelligent switching for growing networks. It offers an extensive suite of advanced Layer 2 switching features and protocols, and also provides Layer 3 routing capability. It offers the forwarding capacity to simultaneously process traffic on all ports at line rate without any packet loss. It’s total non-blocking throughput is 26Gbps, wit 24 Gigabit RJ45 ports, and 2 Gigabit SFP ports.

Product Features:
• (24) Gigabit RJ45 Ports
• (2) SFP Ports
• (1) Serial Console Port
• Non-Blocking Throughput: 26 Gbps
• Switching Capacity: 52 Gbps
• Forwarding Rate: 38.69 Mpps
• Maximum Power Consumption: 25W
• Rack- or Wall-Mountable
• Quiet, Fanless Operation
• Option: Redundant Power Supply Unit (PSU), Used as a Hot Spare
• Ubiquiti Networks EdgeSwitch PSU, 56W
• External PSU (Minimum Power: 25W, 25 to 16V) with 2.5 mm DC Power Inline Connector

Product Specifications
• Dimensions: 443 x 43 x 221mm (17.44 x 1.69 x 8.70″)
• Weight:
Rack-Mount Brackets Included: 2.7kg (5.7lbs)
Rack-Mount Brackets Excluded: 2.51kg (5.54lbs)
• Total Non-Blocking Throughput: 26Gbps
• Switching Capacity: 53Gbps
• Forwarding Rate: 38.69Mpps
• Max. AC Power Consumption: 25W
• Power Method: 100-240VAC/50-60Hz, Universal Input. DC 25V/25W Min.
• Power Supply: AC/DC, Internal, 25W FC
• LEDs per Port:
Serial Console Port: N/A
RJ45 Data Ports: Speed/Link/Activity
SFP Data Ports: Speed/Link/Activity
• Networking Interfaces: (24) 10/100/1000Mbps RJ45 Ethernet Ports + (2) 1Gbps SFP Ethernet Ports
• Management Interface: (1) RJ45 Serial Port, Ethernet In/Out Band
• Certifications: CE, FCC, IC
• Rackmount: Yes, 1U High
• ESD/EMP Protection: Air:±24kV, Contact: ±24kV
• Operating Temperature: -5 to 40°C (23 to 104°F)
• Operating Humidity: 5 to 95% non-condensing
• Shock and Vibration: ETSI300-019-1.4 Standard

Product Includes:
• (1) EdgeSwitch 24-Port Lite Gigabit Switch 25W
• (1) Power Cord
• (2) Rack-Mount Brackets
• (8) M4 Bracket Screws
• (4) #10-32 x 5/8″ Mounting Screws
• (4) #10-32 x 5/8″ Cage Nuts
• (1) Quick Start Guide
