8-Port 10/100M PoE+ Switch with 2 Gigabit Uplink Ports ( FS1010PG )


FS1010PG
● Support IEEE802.3at and IEEE802.3af Standard
● 120W PoE power output totally,up to 32W for one PoE port
● Support IEEE802.3x full duplex and half duplex flow control
● Support VLAN and CCTV Function
● Panel lights to monitor working state and help fault analysis
● Perfect security mechanism
● Line-speed forwarding intelligent identification

DATASHEET

42.03

Specifications



Model FS1010PG
PoE standard IEEE802.3af/at
Interface 10*10/100Mbps The RJ45 port through consultationa
Key function CCTV&VLAN
PoE port 1~8 port
PoE Total 120W
Power supply 120W
RJ45 PoE power supply Mode A     Anode1/2     Cathode3/6
PoE output-port Max 32W
Indicator PWR, LNK/ACT, PoE
Network media 10BASE-T: UTP category 3, 4, 5 cable(≤100m);100BASE-TX: UTP category 5, 5e cable(≤100m);
MAC Address Table 8K, Automatic study, automatic updates
Jumbo frame 1528Bytes
Packet buffer 2M bit
Transfer Mode Store-and-forward
Packet forwarding rate 1.48Mpps
Bandwidth 2M bit
Fan Fanless
Device Dimension 220*150*44mm
Machine Weight >1kg
Green energy saving Support IEEE(802.3az)
Mains Input 100~240V AC, 50/60Hz
Operating Temperature 0°C ~ 40 °C
Storage Temperature -40 °C ~ 70 °C
Operating Humidity 10% ~ 90% non-condensing
Storage Humidity 5% ~ 90% non-condensing
Surge Protection ±4KV
MTBF >50000 hour
Electrostatic standard Contact 4KV, air 6KV
SKU: 7990 Categories: ,
