LHG 5 Tripack

Dual chain 24.5dBi 5GHz CPE/Point-to-Point Integrated Antenna, 600Mhz CPU, 64MB RAM

The LHG 5 is a compact and light 5GHz 802.11 a/n wireless device with an integrated dual polarization 24.5 dBi grid antenna at a revolutionary price. It is perfect for point to point links or for use as a CPE at longer distances and supports Nv2 TDMA protocol.

The grid design ensures protection against wind, and the fact that the antenna element is built into the wireless unit means no loss on cables.

We have two versions available.

  • LHG 5-US (USA) is factory locked for 5170-5250MHz and 5725-5835MHz frequencies. This lock can not be removed.
  • LHG 5 (International) supports 5150MHz-5875MHz range (Specific frequency range can be limited by country regulations).

    Specifications

    Details
    Product code RBLHG-5nD
    Architecture MIPSBE
    CPU AR9344
    CPU core count 1
    CPU nominal frequency 600 MHz
    Dimensions Ø 391 x 222 mm; package 450 x 450 x 145 mm
    RouterOS license 3
    Operating System RouterOS
    Size of RAM 64 MB
    Storage size 16 MB
    Storage type FLASH
    MTBF Approximately 100’000 hours at 25C
    Tested ambient temperature -40°C to 70°C
    Suggested price $59.00

    Powering

    Details
    PoE in Passive PoE
    PoE in input Voltage 11-30 V
    Number of DC inputs 1 (PoE-IN)
    Max power consumption 6 W
    FAN count Passive

    Wireless specifications

    Details
    Wireless 5 GHz Max data rate 300 Mbit/s
    Wireless 5 GHz number of chains 2
    Wireless 5 GHz standards 802.11a/n
    Antenna gain dBi for 5 GHz 24.5
    Wireless 5 GHz chip model AR9344
    Wireless 5 GHz generation Wi-Fi 4

    Ethernet

    Details
    10/100 Ethernet ports 1

    Certification & Approvals

    Details
    Certification CE, FCC, IC, EAC, ROHS
    IP IP54

    Wireless specifications

    5 GHz Transmit (dBm) Receive Sensitivity
    6MBit/s 25 -96
    54MBit/s 20 -80
    MCS0 25 -96
    MCS7 19 -75
