MAG2P – Fire Control Panel
Availability:
Out of stock
MAG2P is a conventional fire alarm panel certified to EN54-2/4 standard, providing 2 fixed zones. Up to 20 (32 SensoMAG Series) fire detectors can be connected to every fire zone. Unlimited number of call points can be connected to each of the fire zones.
MAG2P is situated in a plastic box. The panel is easy for installation and maintenance and provides user-friendly daily operation.
The panel is suitable for residential, small and middle office applications with protected area up to 1000m².
The panel is available in different language versions for the front foil.
Description
- 2 fully monitored fire zones with up to 32 fire alarm detectors and unlimited number of call points
- 2 monitored siren outputs – 300 mA each
- 1 “fire” and 1 “fault” relay output
- Active EOL allowing continuous monitoring of inputs
- “One man” zone testing
- Multilanguage front panels
- LED indication
- Levels of access protected by means of security key
- Plastic box
| Main Power Supply | ~230 VAC ± 10% |
| Frequency | 50/ 60Hz |
| Back-up power supply (battery) | 1 x 12V/ 7Ah |
| Consumption (main power supply and fully charged battery) | 700mA |
| Consumption (main power supply failure) | 50mA |
| Operating temperature | 0°C to 40°C |
| Weight (without battery) | ~2.1kg |
| Dimensions of the metal box | 340x290x100mm |
