mANTBox 15s


RB921GS-5HPacD-15S – mANTBox 15s (5GHz 120 degree 15dBi 2X2 MIMO Dual Polarization Sector Antenna, 720MHz CPU,128MB RAM, 1xGbit LAN, 1xSFP, PoE, PSU, mounting kit, RouterOS L4)

163.00

The mANTBox is based on our new mANT sector antennas, but also has a wireless router built right in. Powered by the RB921 device, the mANTBox comes ready to use with everything included. The device uses a high speed 720MHz CPU and has a built in 802.11 ac/a/n wireless device with up to 31dBm output power.

mANTBox 15s comes with 15dBi 120 degree sector antenna

DATASHEET



Details
Product code RB921GS-5HPacD-15S
CPU nominal frequency 720 MHz
CPU core count 1
Size of RAM 128 MB
10/100/1000 Ethernet ports 1
Wireless chip model QCA9882
Wireless standards 802.11a/n/ac
Power Jack 1
PoE in Yes
Supported input voltage 9 V – 30 V
Voltage Monitor Yes
PCB temperature monitor Yes
Dimensions 140 x 348 x 82 mm
Operating System RouterOS
Tested ambient temperature -30 70 C
License level 4
Antenna gain DBI 15
CPU QCA9557
Max Power consumption 13W
SFP ports 1
Number of chains 2
Storage type NAND
Storage size 128 MB

Wireless specifications

5 GHz
Transmit power (dBm) Receive Sensitivity Transmit power (mW)
6MBit/s 31 -96 1259
54MBit/s 27 -81 501
MCS0 30 -96 1000
MCS7 27 -77 501
MCS9 22 -72 158
