NetMetal 5

142.74

RB922UAGS-5HPacD-NM –¬†NetMETAL 5 (720MHz CPU, 128MB RAM, 1xGigabit LAN, 1xSFP cage, 1xUSB, 1xminiPCI-e, built-in 5Ghz 802.11ac2x2 dual chain wireless with two RP-SMA connectors, RouterOS L4, outdoor enclosure, POE, PSU, pole mount, railmount)

This NetMetal version is equipped with a miniPCI-express slot a SIM slot for 3G/4G device or additional wireless card, a high power 2×2 dual chain 802.11ac wireless and two RP-SMA connectors for external antennas

The NetMetal is a 802.11ac wireless device in a waterproof metal enclosure. Its rugged design is made to withstand the toughest conditions, but at the same time is easy to use and can be opened and closed with one hand. The solid aluminum enclosure also works as a reliable heat-sink for its high output power radio.

The NetMetal is equipped with powerful 720Mhz CPU, 128MB RAM, one Gigabit Ethernet port, 802.11ac wireless, one SFP cage, USB, RP-SMA connectors for external antennas and RouterOS L4 license.

Product specifications

Details
Product code RB922UAGS-5HPacD-NM
SFP DDMI yes
CPU nominal frequency 720 MHz
CPU core count 1
Size of RAM 128 MB
10/100/1000 Ethernet ports 1
MiniPCI-e slots 1
Wireless standards 802.11a/n/ac
Wireless chip model QCA9882
Number of USB ports 1
802.3af support no
Supported input voltage 8 V – 30 V
PoE in Yes
Voltage Monitor Yes
PCB temperature monitor Yes
Dimensions 143x247x48mm (PCB)
Operating System RouterOS
License level 4
CPU QCA9557
Max Power consumption 19W
SFP ports 1
USB slot type USB type A
Number of chains 2
Storage type NAND
Storage size 128 MB

Wireless specifications

5 GHz
Transmit power (dBm) Receive Sensitivity Transmit power (mW)
6MBit/s 31 -96 1259
54MBit/s 27 -81 501
MCS0 30 -96 1000
MCS7 27 -77 501
MCS9 22 -72 158

wireless parameters may be limited in software, depending on your local regulatory limitations
