Outdoor AGC optical receiver WS-OR409

Performance Characteristic
Adopt waterproof aluminum shell and the waterproof level could reach to IP65 grade.
Double shield panel that can ensure the excellent EMC index.
Advanced GaAs low noise amplified circuit increases the receiving sensitivity.
AGC control range +2~-8dBm, output level unchanged. CTB, CSO basically unchanged.
Ten pieces luminescent can show more accurate optical power.
The branch and distribution can be exchanged.
AC – 60v has independent power supply port.
With internal button fuse box, convenient and quick to changeAdopt anti surge lighting circuit that can protect he power supply effectively
Product application
OR409 optical receiver is an outdoor 4 outputs waterproofing receiver. It is mainly used in the building, community or village with concentrated users and high level multi outputs distribution network. Also suitable to be used in the place where it is not convenient to take the electricity and single equipment drives many users. It can work together with ONU or EOC to realize the network convergence. OR409 optical receiver adopts MMIC as the pre-stage amplification and hybrid module in the backward stage. Adjustable attenuation and equilibrium makes the debugging extremely convenient. The users also can choose the module combination according to their actual requirements. Optimized circuit design guarantees the perfect performance and is the ideal model for CATV network.

Outdoor AGC optical receiver WS-OR409
