Mikrotik, RouterBoard
RB450G
The miniROUTER (RouterBOARD 450G) with 680MHz Atheros CPU, 256MB RAM, 5 Gigabit LAN ports, RouterOS L5
The RB450G is a five port Gigabit ethernet router. Comparing to the RB450, the RB450G not only adds Gigabit speed capability, but also 256Mb of RAM, a faster CPU and a microSD card slot for file storage.
The device is powered by a fast AR7161 680MHz Atheros CPU, and also includes a temperature sensor and voltage monitor.
RB450G includes RouterOS – the operating system, which will turn this powerful system into a highly sophisticated router, firewall or bandwidth manager.
Product specifications
| Details | |
|---|---|
| Product code | RB450G |
| 10/100/1000 Ethernet ports | 5 |
| Architecture | MIPS-BE |
| CPU | AR7161 |
| CPU core count | 1 |
| CPU nominal frequency | 680 MHz |
| License level | 5 |
| Memory Cards | 1 |
| Memory card type | microSD |
| Operating System | RouterOS |
| PCB temperature monitor | Yes |
| PoE in | Yes |
| Power Jack | 2 |
| Serial port | RS232 |
| Size of RAM | 256 MB |
| Storage size | 512 MB |
| Storage type | NAND |
| Supported input voltage | 8 V – 28 V |
| Tested ambient temperature | -20°C .. 70°C tested |
| Voltage Monitor | Yes |
