Rocket M5 – Titanium

Specification:



• Processor Specs : Atheros MIPS 74KC, 550 MHz

• Memory Information : 128 MB SDRAM, 8 MB Flash

• RF Connections : 2 RP-SMA (Waterproof ) , 1 SMA (GPS)

• Wireless Approvals : FCC Part 15.247, IC RS210, CE

• RoHS Compliance : Yes

• Dimensions :160 x 80 x 44 mm

• Weight : 350g

• Enclosure Characteristics : Die-Cast Aluminium

• Networking Interface : (1) 10/100/1000 Ethernet Port , (1) 10/100 Ethernet Port

• Max. Power Consumption : 6.5 Watts (RM2-Ti), 8.0 Watts (RM5-Ti)

• Power Supply : 48V, 0.5A PoE Adapter (Included)

• Power Method : 802.3af Compliant

• ESD/EMP Protection : 30KV Contact / Air for Ethernet

• Operating Temperature : -30 to 75° C

• Operating Humidity : 5 to 95% Condensing

• Shock and Vibration : ETSI300-019-1.4

• Modes : Station, Access Point, AP Repeater

• Services : SNMP, DHCP, NAT

• Utilities : Site Survey with Preferred SSID, Antenna Alignment Tool, Discovery Utility

• Security : WEP/WPA/WPA2

• QoS : 802.11e / WMM Support

• Statistical Reporting : Ethernet Activity, Uptime, Packet Success/Errors

• System LEDs : Power, WAN, LAN, GPS (RM5-Ti only)

• Antenna Align / Signal Strength LEDs :Software Adjustable to Correspond to Custom Signal Strength Levels

• Operating Frequency : 5170 – 5825 MHz*

• Range Performance : 50 km (Outdoor – Antenna Dependent)

• Output Power : 27 dBm

UBIQUITI DATASHEET
