SHELLY PLUG S – SMART WALLPLUG WITH POWER METERING (WIFI)

Note 1:

The device only works on 2.4 GHz WiFi b/g/n.

Note 2:

The device does not work only on 5 GHz WiFi ac.

Note 3:

The device supports REST API control and MQTT protocol.

WiFi-operated Plug

Control a wide range of home appliances and office equipment (lights, power lines, security systems, heating radiators, air conditioners, etc.) from anywhere with the smallest WiFi-operated Plug.

Shelly Plug S

• has an embedded webserver
• can function as a standalone device, as an accessory to a home automation controller, or it may be used as another automation system’s component.
• it allows you to manage electrical supplies with power up to 2500W (12A)

Description

• Power supply AC 110-230V ±10%, 50/60Hz
• Power supply DC No
• Device temperature protection Yes
• Overload protection Yes
• Power measurement Yes
• Maximum load 12A
• Operational temperature -10ºC to 50ºC
• Device power consumption < 1 W
• Intelligent On/Off Yes
• Local and remote control Yes
• Sunrise/Sunset Yes
• Weekly Schedule Yes
• Wireless/WiFi Protocol 802.11 b/g/n
• Radio frequency 2400 – 2500 MHz
• Radio signal power 1mW
• Range up to 50 m outdoors and up to 30 m indoors (depending on the building materials)
• Size 46mm x 69mm
