Specification
| MODEL | PRP-300/ PRP-300L |
|---|---|
| General | |
| Print Method | Thermal line printing |
| Print Speed | 250 mm/sec |
| Print Life | 100 Km |
| Print Font (ASCII Mode) | ANK Font Font A: 12 x 24 dots Font B: 9 x 17 dots |
| Print Font (Graphic Font) | Chinese character: 24 x 24 dots |
| Print Resolution | 576 dots/line or 512 dots/line |
| Print Font Character Support * | International Font, Big 5 Chinese, GB Chinese, Japanese, Korean selectable |
| Character Per Line | 48 (Font A) / 42 (Font B) |
| Effective Print Width | 72 mm |
| Paper Width | 79.5mm ± 0.5mm |
| Paper Roll Diameter | ≦ 83mm |
| Paper Thickness | 0.06 ~ 0.08mm |
| Driver | Win7/ Win8/ Win10, compatible with OPOS and ESC/ POS |
| Print Command | ESC/ POS print commands set |
| Auto Cutter | Partial |
| Paper End Detection | Yes |
| Over-Heat Halt-on Protection | Yes |
| Buffer | |
| Receipt Buffer | 128K bytes |
| User-Defined Buffer | 128K bytes |
| NV Flash Buffer | 256K bytes |
| Interface | |
| Serial | Multi I/O Interface (Serial + USB + Ethernet) (USB/ Parallel as optional) |
| Parallel | |
| USB | |
| Ethernet | |
| Cash Drawer | DC 24V/1A, 6-Wire RJ-11 Socket |
| Others | |
| Power Input | 24VDC/2.5A (with External Adapter 100 ~ 240VAC 50/60Hz) |
| Color | Black / White |
| Compliance | FCC/ CE/ WEEE/ RoHS |
| Weight | 1220 g (without cable) |
| Dimension | 174 x 144 x 124 (L x W x H: mm) |
| Operating Temperature | 0°C ~ 45°C |
| Operating Humidity | 10% ~ 80% RH non-condensing |
| Storage Temperature | -10°C ~ 60°C |
| Storage Humidity | 10% ~ 90% RH non-condensing |
