ZTE – F460 EPON ONU

XA10 F460 is an EPON Optical Network Terminal designed for HGU (Home Gateway Unit) used in FTTH scenario. It provides subscriber with rich, colorful, individualized, convenient and comfortable triple-play services including video (IPTV), voice, wireless access, convenient network storage services and high speed internet access. It has a small, smart appearance and green, Energy-saving advantage. Using TR069 and OAM protocol, O&M cost can be reduced effectively by supporting remote service provisioning, intelligent fault diagnosis and performance statistic functions.

General Specifications

Standards:

IEEE 802.3ah,IEEE 802.3,IEEE 802.1D,IEEE 802.1Q,IEEE

802.1ad,IEEE 802.1P,IEEE 802.3x

Network Interface:

EPON Interface: 1 * EPON interface (SC/PC),

Transmission Rate: 1.25Gbps upstream and downstream

User Interface:

LAN: 4*10/100 Base-T interfaces with RJ-45 connector

Voice: 2*POTS interfaces with RJ-11 connector

WLAN: 1*WLAN Interface

USB: 2*USB 2.0 host Interfaces
