CCR1016 is an industrial grade router with a cutting edge 16 core Tilera CPU. If you need many millions of packets per second – Cloud Core Router is your best choice.
This model has twelve SFP ports and one SFP port for 10G connectivity. It is available in a 1U rackmount case and also has a serial console port, a touchscreen LCD and a USB port.
The CCR1016-12S-1S comes with redundant power supplies and one RJ45 SFP 10/100/1000M copper module.
Product specifications
| Details | |
|---|---|
| Product code | CCR1016-12S-1S |
| CPU nominal frequency | 1.2 GHz |
| SFP DDMI | Yes |
| CPU core count | 16 |
| Architecture | TILE |
| Size of RAM | 2 GB |
| Number of USB ports | 1 |
| Power Jack | 2 |
| Supported input voltage | 24 V – 24 V |
| Voltage Monitor | Yes |
| CPU temperature monitor | Yes |
| Operating System | RouterOS v6 |
| Tested ambient temperature | -20C .. 60C |
| License level | 6 |
| Current Monitor | Yes |
| CPU | TLR4-01680CG-12CE-A3a |
| Max Power consumption | 44W |
| SFP ports | 12 |
| SFP ports | 1 |
| USB slot type | microUSB type AB |
| Serial port | RS232 |
| Storage type | NAND |
| Storage size | 128 MB |
