HAC-HDW1200EMP – 2MP HDCVI IR Eyeball Camera

Availability:

Out of stock


* The parameters and datasheets below can only be

applied to 1200-S5 series

> Max 30fps@1080P

> HD and SD output switchable

> 3.6mm fixed lens (2.8mm, 6mm optional)

> Max. IR length 50m, Smart IR

> IP67, DC12V

Camera
Image Sensor 1/2.7 inch CMOS
Effective Pixels 1920(H)×1080(V), 2MP
Scanning System Progressive
Electronic Shutter Speed PAL: 1/25s–1/100000s
NTSC: 1/30s–1/100000s
S/N Ratio >65dB
Minimum Illumination 0.02Lux/F1.9, 30IRE, 0Lux IR on
Fill Light Working Distance 50 m (164 ft)
IR On/Off Control Auto; manual
IR LED Number 1
Pan/Tilt/Rotation Range Pan: 0°–360°
Tilt: 0°–78°
Rotation: 0°–360°
Lens
Lens Type Fixed-focal
Mount Type M12
Focal Length 2.8 mm; 3.6 mm; 6 mm
Max. Aperture F1.9
Field of View 2.8 mm: 119° x 101° x 54°

(diagonal x horizontal x vertical)
3.6 mm: 100° x 84° x 45°

(diagonal x horizontal x vertical)
6 mm: 60° x 56° x 30° (diagonal x horizontal x vertical)

Iris Type Fixed iris
Close Focus Distance 2.8 mm: 0.5 m (1.7 ft)
3.6 mm: 0.8 m (2.6 ft)
6 mm: 2 m (6.6 ft)
DORI Distance Lens Detect Observe Recognize Identify
2.8 mm 38.6 m (126.6 ft) 15.4 m (50.5 ft) 7.7 m

(25.3 ft)

3.9 m

(12.8 ft)

3.6 mm 49.7 m (163.1 ft) 19.9 m (65.3 ft) 9.9 m

(32.5 ft)

5 m

(16.4 ft)

6 mm 82.8 m (271.7 ft) 33.1 m (108.6 ft) 16.6 m (54.5 ft) 8.3 m

(27.2 ft)

Video
Frame Rate CVI: 1080P@25/30fps; 720P@25/30fps; 720P@50/60fps;
AHD: 1080P@25/30fps; 720P@25/30fps;
TVI: 1080P@25/30fps; 720P@25/30fps; 720P@50/60fps;
CVBS: 960H
Resolution 1080P (1920×1080); 720P (1280×720); 960H (960× 576/960×480)
Day/Night Auto switch by ICR
BLC BLC/HLC/DWDR
WDR DWDR
White Balance Auto; manual
Gain Control Auto; manual
Noise Reduction 2D NR
Smart IR Yes
Electronic Defog Yes
Mirror Off/On
Privacy Masking Off/On (8 area, rectangle)
Certifications
Certifications CE (EN55032:2015, EN 61000-3-2:2014, EN 61000-3-3:2013, EN55024:2010 A1:2015, EN 55035:2017, EN50130-4:2011 A1:2014)
FCC (CFR 47 FCC Part 15 subpartB, ANSI C63.4-2014)
UL (UL60950-1 CAN/CSA C22.2 No.60950-1)
Port
Audio Output One channel built-in mic (-A)
Video Output Video output choices of CVI/TVI/AHD/CVBS by one BNC port
Power
Power Supply 12V ±30% DC
Power Consumption Max 3.2W (12V DC, IR on)
Environment
Operating Temperature -40°C to 60°C (-40°F to 140°F); <95% (non-condensation)
Storage Temperature -40°C to 60°C (-40°F to 140°F); <95% (non-condensation)
Protection Grade IP67
Structure
Casing Mental throughout the whole casing
Camera Dimensions φ106.0 mm × 93.6 mm (φ4.17″ × 3.69″)
Net Weight 0.44 Kg (0.97 lb)
Gross Weight 0.59 Kg (1.3 lb)
