Specification

• Processor Specs Atheros MIPS 74Kc, 560 MHz
• Memory 64 MB DDR2, 8 MB Flash
• Networking Interface (1) 10/100/1000 Ethernet Port
• Wireless Approvals FCC, IC, CE
• RoHS Compliance Yes

• Dimensions 459 x 459 x 261 mm (18.07 x 18.07 x 10.28″)
• Weight 3.22 kg (7.10 lb)
• Power Supply 24V, 0.5A Gigabit PoE
• Power Method Passive PoE (Pairs 4, 5+; 7, 8 Return)
• Supported Voltage Range 18-26VDC
• Max. Power Consumption 8W
• Gain 25 dBi
• Operating Frequency
  Worldwide – 5170 – 5875 MHz
  USA -5725 – 5850 MHz
• Wind Loading 390 N @ 200 km/h (88 lbf @ 125 mph)
• Wind Survivability 200 km/h (125 mph)
• LEDs (1) Power, (1) LAN, (4) WLAN
• Signal Strength LEDs Software-Adjustable to Correspond to Custom RSSI Levels
• Channel Sizes 5/8/10/20/30/40 MHz
• Polarization Dual Linear
• Enclosure Outdoor UV Stabilized Plastic
• Mounting Pole-Mount Kit Included
• ESD/EMP Protection Air: ± 24 kV, Contact: ± 24 kV
• Operating Temperature -40 to 70° C (-40 to 158° F)
• Operating Humidity 5 to 95% Non-Condensing
• Salt Fog Test IEC 68-2-11 (ASTM B117), Equivalent: MIL-STD-810 G Method 509.5
• Vibration Test IEC 68-2-6
• Temperature Shock Test IEC 68-2-14
• UV Test IEC 68-2-5 at 40° C (104° F), Equivalent: ETS 300 019-1-4
• Wind-Driven Rain Test ETS 300 019-1-4, Equivalent: MIL-STD-810 G Method 506.5

UBIQUITI DATASHEET
