The 4GE+1Tel+WIFI(2.4G/5G)+1USB Huawei GPON ONU HS8145V, an optical network terminal (ONT), is a high-end home gateway in Huawei FTTH solution. By using the GPON technology, ultra-broadband access is provided for home and SOHO users. The HS8145V provides 1* POTS ports, 4* GE auto-adapting Ethernet ports, and WIFI(2.4G/5G). The HS8145V features high-performance forwarding capabilities to ensure excellent experience with VoIP, Internet and HD video services. Therefore, the HS8145V provides a perfect terminal solution and future oriented service supporting capabilities for FTTH deployment.
Specification:
| Model Number
|
HS8145V GPON ONU |
| PON | GPON |
| Connector Type | SC/UPC |
| Ports | 4GE+1POTS+1USB+2.4G/5G WIFI |
| WAN | 2.4GHz:2×2 mmo 802.11b/g/n |
| 5GHz:2x3mmo 802.11a/n/ac | |
| Antenna gain | 2dBi |
| Box Dimensions | 27cmx29cmx6cm |
| Box Weight(kg) | 0.65KG |
| Power supply | Output:11~14V DC, 1A |
| Input:100-240V AC, 50/60HZ | |
| Cooling | Passive cooling |
| Max No. Of MAC Address learned | 1024 |
| L2 Forwarding Capability | 200 Mbit/s downstream(with any length packets) |
| 200 Mbit/s upstream(with any length packets) | |
| IPv4 L3 forwarding capability | 2Gbit/s with any length packets in downstream direction |
| 1Gbit/s with any length packets in upstream direction | |
| IPv6 L3 forwarding capability | 2Gbit/s with any length packets in downstream direction |
| 1Gbit/s with any length packets in upstream direction | |
| Configuration method | NMS,Web,or TR069 |
| Voice protocol | SIP, H.248 |
