Huawei EchoLife HG8247H5

Huawei HG8247H5 FTTH is optical terminal Unit with 4GE + 1VOICE + WIFI + CATV firmware SIP developed by Huawei

Huawei HG8247H5 FTTH Product Overview

Huawei HG8247H5 FTTH provides four GE ports, one POTS ports, one CATV port, one USB port, and supports 2.4G Wi-Fi. The ONT features high-performance forwarding capabilities to ensure an excellent experience with VoIP, Internet, and HD video services. These features make the EG8247H5 a perfect option for broadband access.

Huawei HG8247H5 FTTH Product Pictures

Huawei HG8247 FTTHHuawei HG8247H5 FTTH YCICT

Huawei HG8247H5 FTTH YCICT 4GE + 2VOICE + WIFI + CATV firmware SIPHuawei HG8247H5 FTTH YCICT

Huawei HG8247H FTTH Specifications

Brand Huawei
Model HG8247H5
Type Routing
Dimensions (H x W x D) 199 mm x 135 mm x 30 mm (without antenna and pads)
Operating Temperature 0°C to 40°C
Operating Humidity 5% RH to 95% RH (non-condensing)
Power Adapter Input 100V to 240V AC, 50 Hz/60 Hz
System Power Supply 11V to 14V DC, 1A
Network-Side Ports GPON
User-Side Ports 1POTS + 4 GE + CATV + 2.4G Wi-Fi + 1 USB
Indicators POWER, PON, LOS, LAN1, LAN2, LAN3, LAN4, TEL, USB, WLAN, and WPS

Huawei HG8247H5 FTTH Product Features

  • Supports configuring the global profile and issuing the XML configuration file on the NMS. To provision ONT services in batches and adjust the network, only a few changes are required.
  • Supports user-defined upgrade policies configured through the NMS. The device is automatically upgraded after being powered on and no manual operation is required.
  • Supports remote performance management of the HG8247 through the NMS. By collecting. the performance data, the network performance exception can be monitored in real-time.
  • Supports remote fault locating of the HG8247 through the NMS. Through alarm reporting and remote loopback diagnosis, the fault can be located remotely, which decreases the maintenance cost.
