Overview
CATV GPON ONT HG8321V Optical Network Terminal
1GE 1FE 1POT CATV
Similar to HG8012H
ENG firmware, ENG interface
Connector type SC/APC
Can be configured by OLT or Web or NMS
Suitable for home and SOHO users
Compatible with Huawei/ZTE/Nokia OLT that supports OMCI
Tech Specs
| Specification | |
| Working environment | Operating temperature: 0ºC to 40ºC |
| Environment humidity: 5% to 95% (noncondensing) | |
| Pressure environment: 0 to 106 kPa | |
| Power consumption | Static power: 2 W |
| Maximum power consumption: 2.5 W | |
| Power specifications | Power adapter input: 100 to 240 V AC, 50–60 Hz |
| System power supply: 11–14 VDC, 0.5 A | |
| Dimensions (length x width x height) |
82 mm x 90 mm x 27 mm |
| Weight | About 0.5 Kg |
