24-Port 10/100Mbps Switch
,

24-Port 10/100Mbps Switch

Availability:

1 in stock

25.00 € 56.00 €

1 in stock

Koha e arritjes së produktit : 24/11/2025 - 25/11/2025

TE100-S24D (Version v1.0R)

  • Compact form factor
  • 24 x 10/100Mbps Auto-MDIX RJ-45 ports
  • Plug and Play solution
  • 4.8 Gbps switching capacity
Categories: ,
Hardware
Standards
  • IEEE 802.3 10Base-TIEEE 802.3u 100Base-TXIEEE 802.3x Flow Control
Network Media
  • Ethernet: UTP/STP Cat. 5, up to 100m
  • Fast Ethernet: UTP/STP Cat. 5, 5e, 6, up to 100m
Data Rate
  • Ethernet: 10Mbps/20Mbps (half/full-duplex)
  • Fast Ethernet: 100Mbps/200Mbps (half/full-duplex)
Protocol / Topology
  • CSMA/CD, Star
Power Consumption
  • 4.65 watts (max.)
Switch Fabric
  • 4.8Gbps forwarding capacity
Interface
  • 24 x 10/100Mbps Auto-MDIX RJ-45 ports
RAM Data Buffer
  • 1.75Mbits
Filtering Table
  • 8K entries
Diagnostic LED
  • Power, Link/ACT
Power
  • Input: 100~240V, 50/60Hz, 0.4A
  • Output: 5V DC, 2A external power adapter
Dimension
  • 265 x 122.7 x 41 mm (10.4 x 4.8 x 1.6 in.)
Weight
  • 460 g (1.2 lb)
Temperature
  • Operating: 0° ~ 40° C (32° ~ 104° F)
  • Storage: -10° ~ 70° C (14° ~ 158° F)
Humidity
  • Max. 90% (non-condensing)
Certifications
  • CE, FCC
