Specifications
| Parameter | Specification |
|---|---|
| Dimensions | 343.2 × 181.2 × 60.2 mm (13.5 × 7.1 × 2.4") |
| Weight | 633 g (1.4 lb) |
| Enclosure Material | Polycarbonate |
| Mounting | Wall mount, pole mount (mounts included) |
| Pole Mount Diameter | 1–2.5" (25–63.5 mm) |
| Weatherproofing | IPX4 |
| Power Method | PoE |
| Max Power Consumption | 9 W |
| Supported Voltage Range | 44–57 V DC |
| Includes PoE Adapter | Yes |
| NDAA Compliant | Yes |
| Certifications | CE, FCC, IC, Anatel: 01653-18-08356 |
| Coverage Area | 185 m² (2,000 ft²) |
| Max Client Count | 250+ |
| Uplink | Gigabit Ethernet |
| Networking Interface | (2) GbE RJ45 ports |
| LEDs | System, Status |
| WiFi Standard | WiFi 5 (802.11ac) |
| Spatial Streams | 6 |
| MIMO (5 GHz) | 3×3 DL MU-MIMO |
| MIMO (2.4 GHz) | 3×3 DL MU-MIMO |
| Max Data Rate (5 GHz) | 1.3 Gbps (BW80) |
| Max Data Rate (2.4 GHz) | 450 Mbps (BW40) |
| Antenna Gain (5 GHz) | 8 dBi |
| Antenna Gain (2.4 GHz) | 8 dBi |
| Max TX Power (5 GHz) | 22 dBm |
| Max TX Power (2.4 GHz) | 22 dBm |
| Max BSSIDs | 8 per radio |
| Channel Bandwidth | HT 20/40, VHT 20/40/80 MHz |
| Supported Data Rates (802.11ac) | 6.5 Mbps – 1300 Mbps (MCS0–MCS9, NSS1/2/3) |
| Supported Data Rates (802.11n) | 6.5 Mbps – 300 Mbps (MCS0–MCS15, HT20/40) |
| Wireless Meshing | Yes |
| Band Steering | Yes |
| 802.11v BSS Transition | Yes |
| 802.11r Fast Roaming | Yes |
| 802.11k RRM | Yes |
| Advanced Radio Management | Yes |
| Passpoint (Hotspot 2.0) | Yes |
| Captive Portal | Yes |
| Custom Branding Landing Page | Yes |
| Voucher Authentication | Yes |
| Payment-Based Authentication | Yes |
| External Portal Server Support | Yes |
| Password Authentication | Yes |
| Guest Network Isolation | Yes |
| Private Pre-Shared Key (PPSK) | Yes |
| WiFi Speed Limiting | Yes |
| Client Device Isolation | Yes |
| WiFi Schedules | Yes |
| RADIUS over TLS (RadSec) | Yes |
| Dynamic RADIUS VLAN | Yes |
| Operating Frequency (US/CA) | 2.4 GHz: 2400–2472 MHz5 GHz: 5150–5850 MHz |
| Operating Frequency (Worldwide) | 2.4 GHz: 2400–2483.5 MHz5 GHz: 5150–5725 MHz |
| Operating Temperature | −40 to 70 °C (−40 to 158 °F) |
| Operating Humidity | 5–95% non-condensing |
| Management Application | UniFi Network |
| Software Requirement | UniFi Network v6.0.45 or later |
