Fiber Optic Termination Box 86 type


With metal inside without adapter
The indoor 86mm type FTTH mini fiber optic face plate employs a compact plug-in design,combines a modern design concept, adopts imported plastic, is of a graceful apperarance and applicable for FTTH, FTTO and FTTD, etc., and allows easy use in different installation environments.

Dimensions 86*86*21
Number of ports 2 ports (1 in and 1 out)
Acess cable size 3.0×2.0mm drop cable or indoor cable
 Fiber type  SM&MM
Fiber cladding diameter 125um(G652&G657)
Suitable connector type SC/LC
Operating temperature -40 ~ 85 C
Color White
Insertion loss <0.2dB
Return loss >50dB(UPC),>60dB(APC)
