Municipal enterprises, telecommunications and other enterprises often have to carry out underground pipeline construction wiring,in the traditional cable and cable construction process is difficult, time limit is tight, inevitably need a large number of manpower, and the construction period is long; With science and technology as the first productivity, our company has developed an efficient and time-saving cable tractor, once on the market, solved a major problem in cable construction.
The cable tractor is suitable for the construction of cable buried pipeline. During the construction process, the machine always maintains a smooth running cable, without stacking cables, pressing cables, wrong cables, at the same time make the cable unit length under pressure, tension less than the safety parameters, do not damage the cable
|
Product name
|
Crawler Type Cable Tractors
|
|
Key words
|
Fiber Optical Cable Duct Rod Pusher Cable Pulling Traction Machine
|
|
Traction
|
>300 KG
|
|
Traction speed
|
0-1.5 m / s
|
|
Max opening size of the delivery port
|
5mm-45mm
|
|
Opening angle
|
0-90 °
|
|
Applicable cable
|
4-288 core / 7 * 2.6 / 4 * 35 squire meter or less (optical cable / steel hinge / cable)
|
|
Belt size
|
circumference 1000mm * width 60mm * thickness 12mm
|
|
Engine Fue/Tank |
3 liters (90/92# gasoline) |
|
Power
|
5KW
|
|
Size
|
80 * 60 * 80cm / length * width * high
|
|
Weight
|
120KG
|
|
Gear
|
slow pull, neutral, fast pull, reverse
|
