♦ Expert OTDR：Professional measurement,curve/list/map are displayed simultaneously
♦ Auto OTDR: no complex settings,one key test
♦ OPM supports CW/270/330/1k/2kHz frequency identification
♦ VFL and LS can run in the background, multi task can be operated simultaneously
♦ LS supports CW/ modulation mode output with adjustable output power
♦ RJ45 cable tracker of digital radar,stronger anti-jamming ability
♦ Auto OTDR, expert OTDR, event map, OPM, LS, VFL, RJ45 cable tracking, RJ45 cable sequence,RJ45 cable length, end face detection, flashlight optical loss test
♦ RJ45 cable sequence/cable length test, up to 300m
♦ One click screen capture, easy to save the interface
| Type | G.652 SM |
| Wavelength | 1310/1550±20nm |
| Dynamic Range | 26dB/24dB |
| Event Blind Zone | 2.5m |
| ATT Blind Zone | 8m |
| Test Range | 500m/1km/2km/4km/8km/16km/32km/64km/100km |
| Pulse Width | 3ns/5ns/10ns/20ns/30ns/50ns/80ns/160ns/320ns/500ns/800ns/1μs/2μs/3μs/5μs/8μs/10μs |
| Ranging Accuracy | ±（1m+Sample interval+0.005％×Test distance） |
| Linearity | ≤0.05dB/dB |
| Sample Points | 16k~128k |
| Sample Resolution | 0.05m~8m |
| Loss Resolution | 0.001dB |
| Loss Threshold | 0.20dB |
| Range Resolution | 0.001m |
| Refractive Index | 1.00000~2.00000 |
| Reflection Accuracy | ±3dB |
| File Format | SOR Standard File Format |
| Loss Analysis | 4-point method /5-point method |
| Laser Safety Level | Class Ⅱ |
| Connector | FC/UPC（Interchangeable SC、ST） |
