| Model | AP-3024GE | |
|
Port Characteristic |
Connector Type | 1×4 RJ45，1×1 RJ45, 1 SFP |
| Transmission rate | 10/100/1000Mbps auto-negotiate | |
|
Port Function |
Power supply priority, fast transmission, MAC automatic learning and aging, IEEE802.3X full-duplex and
backpressure half-duplex |
|
| Indicator Light | Each port has 1 Link/ACT 100Mbps and 1 power light; whole machine power indicator; VLAN indicator | |
| Transmission Speed | 100BASE-T:14880PPS/PORT
1000BASE-TX:14800PPS/PORT |
|
|
Exchange performance |
Forward method | Store-and-forward（full wire-speed） |
| MAC address table | 2K | |
| Bandwidth | 12G | |
|
Power parameters |
Input voltage | AC100~240V |
| Power consumption | 65W | |
| PoE pin | 1/2+, 3/6- | |
| The port max rate | ≤30W | |
|
Environment |
Operating Temperature | -20℃～60℃ |
| Storage Temperature: | -30℃ to 70℃ | |
| Operating Humidity | 90% non-condensing | |
| Storage humidity | 95% non-condensing | |
| Physical properties | Size | 200*142*43mm |
| Weight | 1 KG | |
