| Access Channels |
5 Channels |
| Incoming Bandwidth |
60 Mbps |
| Outgoing Bandwidth |
40 Mbps |
| Supported Resolution |
6MP / 5MP / 4MP / 3MP / 1080P / UXGA / 720P / VGA / 4CIF / DCIF / 2CIF / CIF / QCIF |
| Preview Decoding |
6MP×1, 5MP×1, 4MP×2, 3MP×2, 1080P×4, 720P×5, 4CIF×5 (30fps) |
| Playback Decoding |
6MP×1, 5MP×1, 4MP×2, 3MP×2, 1080P×4, 720P×4 (30fps) |
| Video Compression |
S+265 / H.265 / S+264 / H.264 |
| Audio Compression |
G711A / G711U / ADPCM_DIV4 |
| Stream Type |
Video / Video & Audio |
| Third-party Camera Access |
ONVIF (Profile S/T) / RTSP |
| HDMI Output |
Up to 3840×2160 (4K @30Hz) |
| VGA Output |
Up to 1920×1080 (60Hz) |
| Multi-screen Display |
VGA & HDMI simultaneous output (1 / 2A / 2B / 3 / 4 / 5 / 6 split modes) |
| Network Interface |
1×RJ-45 (10/100 Mbps self-adaptive) |
| Network Protocols |
802.1X, ARP, DDNS, DHCP, DNS, HTTP, HTTPS, ICMP, IGMP, IPv4, IPv6, NFS, NTP, RTSP, RTP, SMB/CIFS, SMTP, SRTP, SSH, TLSv1.2, TCP/IP, UDP, UPnP |
| Mobile Access |
Android / iOS (P2P) |
| System Compatibility |
RTSP / CGI / SDK |
| Web Support |
IE10+, Firefox52+, Edge89+, Safari11+, Chrome57+ |
| Multi-channel Playback |
4 Channels |
| Record Mode |
Manual / Alarm / Schedule |
| Storage Method |
Local HDD |
| HDD Capacity |
Up to 8TB per HDD |
| SATA Interface |
1×SATA |
| Disk Group |
1 Disk Group |
| Backup |
USB Storage / Network |
| Playback Functions |
Play / Pause / Stop / Slow / Speed / 30s Back / 30s Forward / Full Screen / Digital Zoom / Instant Replay / Video Editing |
| General Alarm |
Motion Detection / Mask Alarm / IPC Alarm Input |
| Exception Alarm |
Video Loss / Network Disconnect / No Disk / Disk Full / Disk Error / Illegal Access / IP Conflict / MAC Conflict / PoE Overload / RTC Failure |
| AI by Camera |
Tripwire / Perimeter / Object Abandon / Object Missing / Running / Parking / Crowd Detection / Face Detection / Human & Vehicle Classification / Loitering |
| VCA Search |
Early-warning Search / Face Search |
| Face Attributes |
Gender / Age / Glasses / Face Mask |
| USB Ports |
2×USB2.0 |
| HDMI Port |
1×HDMI |
| VGA Port |
1×VGA |
| PoE Ports |
4×RJ45 (10/100 Mbps) |
| PoE Budget |
45W |
| Max Power per PoE Port |
30W |
| PoE Standard |
IEEE 802.3af/at |
| Power Supply |
DC48V 1.35A |
| Power Consumption |
<10W (without HDD & PoE) |
| Operating Temperature |
-10°C ~ +55°C |
| Storage Temperature |
-20°C ~ +60°C |
| Operating Humidity |
10%–90% RH (non-condensing) |
| Dimensions |
200 × 200 × 43 mm |
| Net Weight |
0.45 kg |
| Gross Weight |
1.25 kg |
| UI Languages |
English, Albanian, German, French, Italian, Spanish, Turkish, Russian, Arabic, Polish, Dutch, Greek, Portuguese, Ukrainian, Vietnamese, Thai, Korean, Chinese (Traditional & Simplified), Indonesian, Hebrew |
| Package Contents |
NVR / Screw Pack / Mouse / Power Adapter / EU Power Cord |
