UACC-Lock-Strike-Secure-15mm
104.59 €
Ubiquiti UACC-Lock-Strike-Secure-15mm UniFi Access Electric Strike Door Lock
The Ubiquiti UACC-Lock-Strike-Secure-15mm UniFi Access Electric Strike Door Lock is a fail-secure lock that connects to a UniFi Access Hub (sold separately, see accessories tab).
Key Features
- Holds up to 1,200 kg (2,645 lb).
- Can be installed on aluminium, steel, or wooden door frames.
- Short and long front plates are included.
Fail-Secure Electric Strike Lock
The Ubiquiti UACC-Lock-Strike-Secure-15mm is a fail-secure electric strike lock designed for seamless integration with the UniFi Access system. It connects directly to a UniFi Access Hub (sold separately), allowing centralised control and monitoring of access events. The “fail-secure” design ensures that the door remains locked in a power-off situation, enhancing security. The device mounts into a standard aluminium, steel, or wooden door frame, with a slim 15mm profile to accommodate tighter installations while retaining strength and reliability.
Dimensions
- Lock body: 80 x 40 x 35 mm (3.2 x 1.6 x 1.4 in)
- Short front plate: 124 x 32 x 3 mm (4.9 x 1.3 x 0.1 in)
- Long front plate: 202 x 36 x 3 mm (7.9 x 1.4 x 0.1 in)
Weight
- Lock body: 185 g (6.5 oz)
- Short front plate: 50 g (1.8 oz)
- Long front plate: 130 g (4.6 oz)
Enclosure materials
- Lock body: zinc alloy
- Front plate/latches: stainless steel
Hardware Specifications
Holding force
- Lock: 1,200 kg (2,645 lb)
Lock type
- Fail secure lock
- Single door
Wiring connection
- Connect the two screw terminal separately to powered lock relay on UA-Hub: NO, COM
Current power
- 400mA ±10%
Supported voltage Range
- 12V DC
Compatibility
- Wooden, steel, aluminium door
Screw terminal
- + and -
Ambient operating temperature
- -10°C to 45°C (14°F to 113°F)
Ambient operating humidity
- 5 - 90% non-condensing
Certifications
- FCC, IC, CE
